3 Ton Light Flat Bed Cargo Truck Diesel 143HP Manual Left Hand Drive 4x2
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
Negotiable
Brand:
EHY
Product Description
3t Light Flat Bed Cargo Truck Diesel Box Truck Flatbed Truck for Sale Africa
Specification of 4x2 truck
| 143HP CRAGO TRUCK | |
| Parameters of chassis | |
|
Cabin |
Q28 Flat top cab/no berth/with thermal insulation cab/seats 3 people/with reversing video/center control touch-sensitive electronic screen/air conditioning/metal bumper/electric doors and Windows/center control lock / independent diesel heating/With low temperature start function |
|---|---|
| Driving Type | Manual left hand drive |
| Drive Wheel | 4x2 |
| GVW | 8000(kg) |
| Curb weight | 3500(kg) |
| Loading capacity | 5000(kg) |
| Overall dimensions | 6000*2200*2700 (mm) |
| Box dimensions | 4200*2200*550(mm) |
| Number of axles | 2 |
| Front axle | 2T |
| Rear axle | 5T |
| Frame | 188*800(mm) double layer |
| Suspension | Multi leaf spring suspension front and rear |
| Wheels and tires | 7.50R16,with one spare tire |
| Brake | Air brake with ABS |
| Air reservoir | Aluminium alloy |
| Battery | Camel battery , 12V |
| Fuel tank | Aluminium alloy tank |
| Pipeline | Low temperature oil and gas pipeline |
| Rear trailer hook | With rear circuit and air circuit interface |
| Parameters of engine | |
| Model | JE493ZLQ5G |
| Function | With low temperature start function |
| Fuel | Diesel |
| Emission standard | Euro 5(Shield exhaust treatment system) |
| Transmission | Manual WLY, 6GS46 ,6 forward |
| Number of cylinder | 4 |
| Rated speed | 3000(r/min) |
| Max.Torque | 350N.m/1400~2400r/pm |
| Power | 105/143(kw/hp) |
| Displacement | 2.771(L) |
| Cargo box parameter | |
| Box dimension | 4200x2200x450(mm) |
| The thickness of the side | 2mm |
| The thickness of the bottom | 3mm |
| Box material | Carbon steel Q235 |
| Paint | Electrophoretic spraying process |
