China Isuzu Jmc Pickup Van Ambulance Pickup Salon Ambulance for sale

Isuzu Jmc Pickup Van Ambulance Pickup Salon Ambulance

Price Negotiable

Price: 15000-35000 per unit

MOQ: 1

Delivery Time: Negotiable

Brand: CLW

Product Description

ISUZU JMC Pickup van ambulance Pickup Salon Ambulance

1. Special strong exhaust: exhaust volume: > 600m3/ h power 12V, 150W

2. High-efficiency filtration device: filter material: effective area of ultrafine glass fiber: 0.15m2 maximum air passage rate: 0.8m /S filtration rate: 0.3 micron for particle size, reaching more than 99.995% (standard 99.7%). Service life: the average life is 8-12 months (related to the starting time of the negative pressure system)

3. Sterilization device: ozone output: 2 g/h power: 220V 70W

4. Primary filtration device: (activated carbon dust removal) filtration level: G3, air inlet flow rate: 200 m3/ h

Specification of Mercedes-Benz Rescue Ambulance

Technical Parameters
Technical parameters of truck chassis
A	Size and Weight
	Wheelbase(mm):		3300
	Dimension(mm):		5521X2032X2590
	Curb weight(kg):		2560
	Engine
	Model:		DURATORQ4D205L
	Fuel type:		Diesel
	Displacement(ml)		2000
	Emission standard		Euro V
	Rate power kw(hp):		89kw/121HP
	Transmission system
	Manual gear box:		5 Forwards & 1 reverse
	Max.Speed(km/h):		≥120
Standard configuration
B	1	Anti collision steel beam
	2	Center control door lock
	3	Leather steering wheel
	4	Two set in cabin
	5	Air bag
	6	Tea table box in cabin
	7	Stereo tape recorder+CD
	8	Rear mirror
Technical parameters of super structure
C	Air conditioner and Exhaust system
	1	Cabin air conditioner
	2	Medical warehouse air conditioner			1
	3	Bidirectional exhaust fan in medical warehouse			1
Disinfection and Light system
D	1	Medical warehouse daylight lamp(Self bright function in night)			4
	2	Ultraviolet disinfection lamp in medical warehouse			1
E	Center power system
	1	1000W power inverter system			1
	2	12V power socket			2
	3	220V power socket			2
	4	Integrated control protection system			1
	5	AC circuit protection system			1
	6	Integrated Switch Control Panel			1
	7	Intercom system			1
	Emergency alarm system
F	1	Alarm lights controller mounted on cabin			1
	2	100W car speakers built in interior of the long rows lights			1
	3	Blue flashing LED lights mounted on rear of the car roof			2
	4	Blue flashing LED lights mounted on right and left side of the car roof			2
	5	White flashing LED lights mounted on right and left side of the car roof			2
	6	Long rows lights mounted on front of the car roof			1
Oxygen Supply System
G	1	2 sets of 10L oxygen cylinder with fixed support			2
	2	Humidifier fast conversion interface			1
	3	Humidifier			1
	4	Built-in type Oxygen pipeline			1
	5	Oxygen terminal			2
H	Medical warehouse device
	1	Polymer Hard Top Interior
	2	Partition wall of polymer material
	3	Transparent push-pull observation window for middle partition
	4	Left top Walker plate long hanging cabinet
	5	Left middle Walker plate Medical Devices and Lockers
	6	Rear left Walker plate Vertical oxygen cabinet
	7	Installation of hidden safety embedded parts throughout vehicle
	8	Full blue collision walls in medical warehouse
	Seat System
	1	Reverse folding seat			1
	2	Right side forward mounted standalone back seat			1
	3	Long horizontal soft seat with seat belt			1
	Rescue Stretcher
	1	Automatic loading stretcher and Stretcher guide			1
	2	Stable Folding transfusion hanger			1
	Safety System
	1	Fire extinguisher			1
	2	Safety handrail			1
Technical parameters of Negative Pressure ambulance Device
I	1	Overall size of negative pressure box(mm)		620420320
	2	Medium efficiency filter size(mm)		45030021
	3	High efficiency filter size(mm)		45030046
	4	Voltage(V)		12
	5	Current(A)		≤20
	6	Exhaust volumem(m³/h)		≥800
	7	Negative pressure range(Pa)		20~30
	8	Error range(Pa)		1.0
	9	Effective filtering		99.995@0.3um
	10	Ventilation rate		25 times/h

Iisuzu Jmc Pickup Van Ambulance Pickup Salon Ambulance
