DONGFENG 8cbm Sewage Suction Truck 4x2 Vacuum Pump Tanker Euro V 160HP
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
30 Days
Brand:
EHY
Product Description
DONGFENG Sewage Suction Truck 12cbm Waste Water Vacuum Pump Truck 4X2 High Pressure Cleaning HOWO 6X4 Vacuum Tank Truck
Description:
- Chassis:
1) Drive type: 4x2, 4x4, 6x4, 8x4 etc.
2) Our factory has good business relationship with DONGFENG, FOTON, ISUZ, FAW, SINOTRUCK, SHACMAN, JAC, JMC, etc. - Tanker body:From 2m3 to 25 m3 capacity.
- Accessory of sewage suction factions: Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.
| Cabin | Driving type 4x2, single row | |
|
Vehicle Main Dimensions |
Overall dimensions (L x W x H)mm | 6800×2300×2850 |
| Wheel base (mm) | 3800 | |
| Wheel track (front/rear) (mm) | 1960/1860 | |
| Approach/Departure angle(°) | 28/32 | |
|
Weight in KGS |
Tare Weight | 5340 |
| payload | 6025 | |
| Front axles loading capacity | 2700 | |
| Rear axles loading capacity | 5000 | |
| Max. driving speed(km/h) | 95 | |
|
Engine |
Brand | Yuchai |
| Horse Power(HP) | 160HP | |
| Emission standard | Euro V | |
| Gearbox | 6 forwards & 1 reverse | |
| Steering | Left hand drive | |
| Tire | 9.00R20, 6 tires with one spare | |
| Sewage Tank | ||
| Tank volume | 8000Liters | |
| Tank material | 6mm carbon steel Q235 | |
| Tank size | 4200x1600mm | |
| Vacuum Pump | Chinese Vacuum Pump or Italy Vacuum Pump | |
| Sewage suction pipe | 7M | |
| Main Performance | Suction time ≤ 5min, effective suction range ≥ 8m |
|
| Other equipment | Oil-gas separator, water-gas separator, four-way valve, anti-flow valve, washing device, pressure gauge, ball valve | |
| Painting | Customized painting color and logo as required. | |
