Isuzu 28m Aerial Work Platform High-Altitude Working High Platform Operation Truck
- Automatic Bucket Balance System, Bucket will be Stayed in Balance Level in All Working Time.
- The Stretching Angle Up to 80°, which will be Easier to Handle in All Time.
- Full Computer Control System with Danger Waring System.
- LCD Screen in Both the Bucket and Truck to Display the Working Status.
- Rectangular Shape Arms to Increase the Arm Strength.
- V Shape Leg, H Shape Leg can Adapted to Different Road Condition Increasing the Stability.
1. It uses Japan lSUZU single row cabin chassis, the cab has advanced design with fully automatic welding manipulator ABB.
2. It is telescopic type, which supports to work in narrow places compared with folding types. The working altitude can reach to 18 meters . And the bucket loading capacity is about 200KG with non-slip body.
3. Front H and rear H legs, good stability, which can be operated at the same time or independently, and adapt to a variety of working conditions.
4. Manual controlled, automatic limit, alarming when in dangerous work, excellent safety performance.
5. Slewing mechanism adopts adjustable type, which is easy to adjust.
|
Chassis Specification |
||||
|
Truck model |
CLW5050JGKIS18T |
|||
|
Cab |
lSUZU 100P double row seat cab |
|||
|
Driving Type |
4*2 Left hand driving |
|||
|
Max Speed (km/h) |
90 |
|||
|
Overall dimension (mm) |
7350*2080*2920 |
|||
|
GVW (kg) |
Appro. 5555 |
|||
|
Mass in working order( kg) |
Appro. 5335 |
|||
|
Wheelbase (mm) |
3360 |
|||
|
F/R track base (mm) |
1504/1425 |
|||
|
F/R overhang(mm) |
1065/2125 |
|||
|
Approach/Departure Angel |
27/15 |
|||
|
Tire |
7.00-16 |
|||
|
Clutch |
Single-plate dry diaphragm spring clutch |
|||
|
Steering |
Hydraulic steering with power assistance |
|||
|
Gear box |
MSB 5-speed |
|||
|
Bridge |
Front axle |
2.5T |
||
|
Rear axle |
4.8T |
|||
|
Engine |
Model |
4JB1CN |
||
|
Fuel Type |
Diesel fuel |
|||
|
Emission Standard |
Europe 4 |
|||
|
Type |
Water-cooled four-stroke, supercharged inter-cooling |
|||
|
Exhaust (ml) |
2771 |
|||
|
Max output power/rotate speed (hp /rpm ) |
98/3400 |
|||
|
Max torque/rotate speed (N.m/rpm) |
220/1700 |
|||
|
BrakingSystem |
Service Brake |
Oil brake |
||
|
Park Brake |
Spring energy |
|||
|
Electric system |
24v |
|||
|
Special Function |
||||
|
Working height (m) |
18 |
|||
|
Max working radius (m) |
9 |
|||
|
Boom type |
Four sections telescopic boom |
|||
|
Rated loading in the bucket(kg) |
200 |
|||
|
Bucket size (mm) |
1000*650*1200 |
|||
|
Rotating speed (r/min) |
0-2 |
|||
|
Rotation Angle |
360° |
|||
|
Supporting leg |
foursetshydraulic legs |
|||
|
Span of supporting legs |
Horizontal |
3500mm |
||
|
longitudinal |
4000mm |
|||
|
Boom Control mode |
1.Bucket control 2.Manual operation |
|||
|
Supporting leg Control mode |
Manual operation |
|||
|
Working Condition: |
1.Altitude: 0-4500m 2.Temperature: -350C~+450C 3.Relative humidity: 80% 4.Wind force: ≤8 degree |
|||
