Industrial Metal Detector For Biscuit Industry , Food Safety Detector Conveyor Belt Type
Food grade metal detector / Metal Detector for food, pharmaceutical, plastic, chemical, toy industry
Are metal detectors essential in a food business?
Any type of metal contamination in your product is definitely a food safety issue – I am sure we can all agree on that. I have pretty strong views around this subject mainly because I have observed so many metal detectors fail to detect metal imbeded in the product when tested during a certification audit.
Any good metal control program first starts with prevention rather than detection. You need to stop the metal contamination from happening in the first place. My first step would be to implement a suitable preventative maintenance program and foreign matter prevention program. Both programs should have adequate monitoring to ensure that the programs are being successfully implemented.
To strengthen your program you can then look at detection and removal equipment including magnets, metal detectors, sieves, visual, xray etc.
Product advantages:
- Mechanism exported from Germany, Dual-channel metal detection system. Coil with a rectangular aperture (no points).
- Control system: ADLINE microprocessor controller.
- Conveyors: Joint-body PU (polyurethane) Conveyor.
- Combined with two-way signal detection circuit technology, liquid crystal display operations in English and visualization.
- Has the adjustment function of products effect, such as moist products, products including sugar or salt, they all can make the machine has the signal of metal, which is actually has no metal, so it gets wrong information from the products and affect the detection result. So use this machine with this function can reduce the products’ effect to get better detection result.
- With memory and learning function, can store 100 kinds of product testing parameters, detecting a wide range of materials.
- Completed by the digital signal processing circuit can detect all metal objects, adjusting the simple, stable and reliable.
- The combination of DSP and micro-controller data items on the test sample and treatment to improve detection.
- Special transport mechanism designed the max-Mize sensitivity of metal detectors.
- Flexible modular design can be customized according to different requirements.
- Mirror stainless steel with open transport system. Easy to clean .
- Meet the requirements of IFS and HACCP certification. There are a variety of options excluded institutions depending on the application.
- With superior shock interference.
Application :
Food industry
Medical industry
Food additives
Baby products
Health products
Other industry that need reject and detect metals
Warranty
12month labor and parts
Full life technical support
Detail Specification:
| Model | VDF series | ||||||||
| Machine specification | Normal machine | Customized width | |||||||
| (mm)Detection Width | 400 | 500 customized | |||||||
| (mm)Detection Height | 100 | 120 | 150 | 200 | 250 | 300 | 350 | 400 | |
| Detection Sensitivity | Fe(Φmm) | ≥0.8 | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 |
| Non-Fe(Φmm) | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | |
| 304Sus(Φmm) | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | ≥4.5 | |
| Alarm and rejector system | Automatic stop by alarm and sound or push rod or falling drop | ||||||||
| Machine structure | Full structure takes of stainless 304 | ||||||||
| Machine size (mm) | L1520mm×W830mm×H1000mm if customized it will according to customized size | ||||||||
| Machine weight | Around 250KG if customized the weight will different | ||||||||
| Voltage and power | 220V 50Hz 90W | ||||||||
| Load ability | 5-25KG conveyor belt running speed :25-30m/min or customized various | ||||||||
| Height from the earth | 750mm±50mm can customized | ||||||||
| Note :Normal size machine have stocks. Unnormal size machine have to customized | |||||||||
Reject system(optional)
Optional reject 1 :Push rod
Optional 2 flap drop
Optional 3 Air blast
