915M Long Distance Integrated Reader 860MHz - 9608MHz For Warehouse Logistics Management
AD-SM15 is a fixed and compact reader, compatible with ISO 18000-6C standards, its working frequency of 860MHz ~ 9608MHz, compact appearance, excellent reading and writing performance. The reader can be widely used in warehouse logistics management, retail logistics center management, enterprise transportation management, automatic production line management and other fields.
▋Technical Specifications
|
Functional features |
||
|
System parameters: |
ARM7+UHF modules |
|
|
Working frequency: |
National standard(920～925MHz) |
|
|
US standard(902～928MHz) |
||
|
European standard(865～868MHz) |
||
|
Other multinational frequency standards (customized) |
||
|
Identification distance: |
0-15m |
|
|
Group read performance: |
>20 tags |
|
|
Label protocol: |
Support ISO18000-6C (EPC GEN2) protocol electronic tags |
|
|
Frequency hopping mode: |
Wide spectrum frequency hopping (FHSS) or fixed frequency, can be set by software; |
|
|
Way of working: |
|
|
|
Rf Power: |
0-30dBm (power software adjustable) |
|
|
Antenna parameters: |
12dBi Linearly Polarized Antenna (built-in) |
|
|
Supported interfaces: |
|
|
|
Operating voltage: |
9-12V ； |
|
|
Working current: |
200MA； |
|
|
Recognition Tips: |
Beep or LED flash |
|
|
Power consumption: |
<4W |
|
|
Work environment |
||
|
Operating temperature: |
－20℃ ～ +70℃(Beyond the scope need to customize) |
|
|
Working humidity: |
20％ ～ 95％(no condensation) |
|
|
Storage temperature: |
－40℃ ～ +125℃ |
|
|
Physical parameters |
||
|
External dimensions: |
445x445x74MM |
|
|
Net weight: |
4.0KG |
|
|
Gross weight: |
5.0KG |
|
|
Other Notes |
||
|
Secondary development: |
Dynamic link library (DLL) and demo software source code are provided to support secondary development. |
|
|
Note: |
The recognition distance and group reading performance need to depend on the tag performance and the specific application scenario, and can be customized according to requirements |
|
▋Product features
-
Low power, stable and reliable read/write distance;
Fast data read rate;
Tag wake-up recognition;
Multi-region multi-label reading;
Multi-protocol compatibility;
Waterproof appearance design;
