Dry Powder Pillow Sealing Weighing Packaging Machine
Dry powder precision automatic Stainless steel screw weighing packaging machine
Introduction
1. The machine can automatically complete the following tasks: material lifting-screw measurement-coding-bag making-filling-sealing-counting-finished product transportation-finished product finishing
2. Using PLC servo and pneumatic control system, touch screen forms the core of drive control; high reliability and intelligence, and equipped with safety protection.
3. The touch screen can store the packaging process parameters of a variety of different products, which can be used at any time when changing products without resetting.
4. Equipped with a fault display system, faults can be clear at a glance for timely troubleshooting.
5. The punch holder can be customized according to customer needs.
6. This machine has two choices: stainless steel model and carbon steel spray model.
specifications
| Model | 100-1200ml |
| Packing speed | 20-50 bags/min |
| Packing range | 50-1000ml |
| Film width | ≤ 450mm |
| Making bag size | L: 50-300mm, W: 50-210mm |
| Packing accuracy | ≤ ±1%(depends on product) |
| Power | 1.9 KW |
| Power supply | AC220V, 50/60Hz |
| Seal type | 3/4 sides seal, pillow seal |
| Net weight | 350kg |
| Machine dimension | L800 × W1100× H1900mm |
Welcome you to know more on our machine and contact us freely.
