Glass Shot Bag Impact Tester Machine For Safety Glass Testing Impact Resistance OEM ODM
Specialized testing equipment designed to evaluate the impact resistance of toughened and safety laminated glass by measuring penetration resistance under controlled impact conditions.
Specifically engineered for testing impact resistance of toughened glass, measuring the penetration resistance and intensity of toughened glass under different impact heights with consistent mass.
- IEC 61730:2-2004 No.10.10 "Module Rupture Test"
- JJG 128-1999 "Safety Glass Shot Bag Impact Tester"
- GB9962-1999 - Suitable for testing impact resistance of laminated glass
- GB17841-1999 - Suitable for testing toughened glass and semi-tempered glass
| Product Name | PV Module Shot Bag Impact Tester / Tempered Glass Impact Testing Machine |
|---|---|
| Testing Standard | IEC61730-2:2016 Testing |
| Suitable Range | Solar Panel, PV Module, Safety Glass, Tempered Glass |
| Impact Area | 2m × 1m (Customizable) |
| Impact Height | 300mm ~ 1220mm |
| Impactor Mass | 45.5 ± 0.5kg |
| Shot Bag Specifications | Mass: 45±0.1kg, Maximum Diameter: 250mm, Inner Filling Diameter: 2.5~3.0mm |
| Test Framework | Internal Dimensions: 19200+10mm × 8450+10mm with 3mm thickness, 15mm width, hardness A50° |
| Protection Measure | Installation of protection frame |
| Electrical Requirements | 220V 50HZ |
- Customer Inquiry: Technical consultation, requirement analysis, and product recommendation with competitive pricing
- Specifications Customization: Technical drawings, reference photos, and final solution confirmation
- Production & Delivery: Manufacturing according to PO requirements, production progress updates, calibration services, and timely delivery
- Installation & After-Sales: On-site installation support and comprehensive after-sales service
Yes, we are professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment. Every machine includes 12-month warranty after shipment with extended 2 months for sea transportation. For technical support, contact us via email or phone - we provide solutions within 24-48 hours after problem confirmation.
Standard machines in stock: 3-7 working days. Custom orders: 15-20 working days after payment. Urgent requirements receive special priority handling.
Yes, we offer both standard and customized machines according to your requirements, including OEM and ODM services with your logo.
We provide English operation manuals and videos. Most machines are shipped fully assembled - simply connect power and begin operation. On-site installation assistance available when necessary.
