Durability Digital Display Battery High Altitude Low Pressure Test Chamber with 0.5-100kPa Pressure Range
Battery High Altitude Low Pressure Simulation Test Chamber is designed for UL, EN, IEC and other standard test requirements to achieve the low pressure storage state of the sample in a short period of time. The system can automatically control the test cycle, monitor pressure changes throughout the process, and automatically terminate tests.
Simulates battery and battery pack storage conditions at pressure ≤ 11.6kPa and ambient temperature (20 ± 5)°C for 6 hours. Qualification criteria: battery does not explode or catch fire.
GB/T 31485-2015, GB/T 31241-2014, UN 38.3, IEC 62133, UL 1642:2012
- Simulate test environments with various altitude conditions
- Critical for defense and aerospace applications with intense pressure and vacuum conditions
- Application fields: Aviation, aerospace, communications, electronics, electrical appliances
- Test purpose: Ensure maximum quality and reliability for products/materials exposed to various altitude levels
| Parameter | Specification |
|---|---|
| Model | UP-6114 |
| Inner Box Size | 400×400×400mm (W×D×H) |
| Equipment Size | 630×620×1130mm (W×D×H) |
| Inner Box Material | SUS304 stainless steel plate, 3.0mm thick |
| Outer Box Material | Cold-rolled steel plate baking paint treatment, 1.5mm thick |
| Viewing Window | Size 250×250mm, two layers of tempered glass, transparent window with stainless steel mesh |
| Equipment Mobility | Four universal casters for free movement |
| Pressure Range | 0.5-100kPa (commonly used test air pressure: 11.6 kPa) |
| Vacuum Level Display | SMC meter digital display type |
| Control Method | Push-button control |
| Timer | LED digital display, free setting within 0-9999h |
| Pressure Fluctuations | ≤5% |
| Box Door | Single door with left opening and explosion-proof chain |
| Storage Tray | 2 |
| Equipment Weight | 120kg |
| Power Supply | AC220V |
| Power | 1kW |
- Customer Inquiry: Discuss testing requirements, suggest suitable products, provide quotes
- Specifications Customization: Create drawings, provide reference photos, confirm final solution and pricing
- Production and Delivery: Manufacture according to PO requirements, provide production updates, factory/third-party calibration, packing and shipping
- Installation and After-Sales: Field installation and ongoing after-sales support
Yes, we are a professional manufacturer of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment. Every machine includes 12-month warranty after shipment with free maintenance. Considering sea transportation, we extend to 14 months for international customers. For technical issues, contact us via email or phone - we provide solutions within 24-48 hours.
Standard machines in stock: 3-7 working days. No stock: 15-20 working days after payment. Urgent requirements receive special arrangements.
Yes, we offer both standard and customized machines according to your requirements. We provide OEM and ODM services including custom logos.
We provide English operation manuals and videos via email. Most machines ship fully assembled - simply connect power and begin use. On-site installation assistance available when necessary.
