55inch 1.8mm TCL Panel LCD Video Wall Narrow Bezel Splicing Screen
Featuring an ultra-narrow bezel of just 1.8mm and a TCL panel with 1920×1080 resolution, this display delivers a nearly borderless viewing experience ideal for control rooms, conference halls, retail video walls, and public information displays.
Built for 24/7 operation, it supports dual signal transmission via HDMI and RJ45, offers versatile mounting options, and comes with a high-capacity CQC-certified power board for stable long-term performance.
| Category | Specification |
|---|---|
| Bezel | 1.8mm |
| Panel Size | 55 inches |
| Resolution | 1920 × 1080 (FHD) |
| Brightness | 500 cd/m² |
| Contrast Ratio | 4000:1 |
| Viewing Angle | 178°(H) / 178°(V) |
| Color Gamut | 75% |
| Backlight Type | Direct-lit (OD35) |
| Refresh Rate | 60Hz |
| Response Time | 6.5ms |
| Input Ports | HDMI ×1 (4K@30Hz), RJ45 ×1 (video over Ethernet), RS232 ×3, USB 2.0 ×1 |
| Power Supply | AC 200–240V, 50/60Hz |
| Power Consumption | ≤138W (max), <0.3W (standby/off) |
| Operating Temperature | -10°C to 50°C |
| Mounting Options | Wall, embedded, floor-standing, front-maintenance, cabinet |
| Included Accessories | Remote control, power cable, battery, quick guide |
True-to-life visuals powered by 1080p Full HD resolution, delivering crisp details and vibrant colors for mission-critical displays.
Minimized 1.8mm bezels create an almost seamless canvas, allowing content to flow naturally across multiple screens without distraction.
Enjoy consistent brightness and color from any angle with 178° wide viewing, perfect for open spaces and wide-angle viewing environments.
Advanced image processing ensures perfect alignment and uniformity across the entire display, delivering a cohesive and uninterrupted viewing experience
Pioneering hybrid connectivity—transmit video via HDMI or Ethernet for cost-effective installation and simplified cabling infrastructure.
-
Control Rooms & Monitoring Centers – 24/7 surveillance and data visualization
-
Corporate & Conference Rooms – Large-format presentations and video conferencing
-
Retail & Advertising Video Walls – Dynamic promotional displays
-
Public Information Displays – Airports, stations, museums, and lobbies
-
Broadcast & Entertainment – Studio backgrounds and event staging
-
✅ Nearly Seamless Visuals – 1.8mm bezel ensures minimal distraction between screens.
-
✅ Dual Signal Inputs – HDMI and RJ45 provide flexible and cost-effective cabling options.
-
✅ Industrial-Grade Reliability – CQC-certified 188W power board supports continuous operation.
-
✅ Easy Integration – Compatible with video wall processors, matrix switchers, and control systems.
-
✅ Wide Compatibility – Supports standard video wall layouts (2×2, 3×3, 4×4, etc.) and creative configurations.
