46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen
Price:
$ 312 - 410 / Unit
MOQ:
4
Delivery Time:
3-15 Work Days
Brand:
YOMURA
Product Description
46" 55" 1.7mm Ultra Narrow Bezel LCD Video Wall 2x2 3x3 Splicing Screen
Professional-grade 55-inch LCD display panel, specifically engineered for ultra-seamless video wall installations. Featuring an ultra-narrow bezel width of just 1.7mm and built with industrial-grade reliability, it is ideal for control rooms, corporate lobbies, and digital signage. The panel supports flexible configurations such as 2x2, 3x3, and larger MxN matrix arrangements to create expansive, high-impact visual displays.
1. Product Overview
| Item | Specification |
|---|---|
| Screen Size | 55 inch (46-inch model details not in this sheet, but may be available in the product line) |
| Bezel Width (Seam) | 1.7mm |
| Panel Technology | A-si TFT-LCD, IPS |
| Aspect Ratio | 16:9 |
| Surface Treatment | Matte anti-glare |
✅ 2. Display Parameters
| Parameter | Value / Description |
|---|---|
| Resolution | 1920 × 1080 (FHD) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 4500:1 (Typ.) |
| Color Depth | 8bit, 16.7M colors |
| Color Gamut | sRGB 98%, NTSC 75% |
| Pixel Pitch | 0.63mm × 0.63mm (~40 PPI) |
| Viewing Angle | 178° (H) / 178° (V) |
| Response Time | 8ms (G to G) |
| Refresh Rate | 60Hz |
| Backlight Type | DLED (Direct LED) |
| Default Color Temperature | 6500K |
| Lifespan | 50,000 hours |
✅ 3. Interfaces & Control
| Type | Interface / Function | Description |
|---|---|---|
| Input | HDMI ×1 | Supports up to 3840×2160@30Hz, 10bit/8bit color formats |
| RJ45 (Network) ×1 | Compatible with Nova Es series / NMX matrix; max. 50m transmission @1080p60 | |
| Control | RS232 IN ×1 (RJ45) | For PC control or IR receiver connection |
| RS232 OUT ×2 (RJ45) | For daisy-chain control or signal loop-out | |
| Other | USB ×1 | Firmware update / USB media playback |
| Remote | Infrared Remote | Effective distance <10 meters |
