Rhinestone Plate Auto CNC Drilling Machine 1.5KW For Carving And Cutting
Price:
USD 1750-4000
MOQ:
1PC
Delivery Time:
5-10 working days
Brand:
LEDIO
Product Description
Automatic Hotfix Crystal Setting Machine Drilling and Cutting
The 6090 and 1313 CNC Router are space-saving and cost-effective solutions for engraving, milling and cutting. They are easy to learn, compatible with common design software, and perfect for small businesses, studios and hobbyists.
6090 1313 CNC Router: Multi-material engraving & cutting with high accuracy and cost efficiency.
Application
Applicable Industries: Advertisement signs/ marks/ brands/ Blister light box mould/ casting mould/ circuit board manufacture/
electroplating drill/ art craft works/ crystal works/ wood products/ decoration/ upholster and other related industries.
electroplating drill/ art craft works/ crystal works/ wood products/ decoration/ upholster and other related industries.
Specification
|
Condition
|
New
|
|
Range of Spindle Speed(r.p.m)
|
1rpm - 24000rpm
|
|
Positioning Accuracy (mm)
|
0.05mm
|
|
Number of Axes
|
3
|
|
No. of Spindles
|
Single
|
|
Working Table Size(mm)
|
600×900
|
|
Machine Type
|
CNC Router
|
|
Travel (X Axis)(mm)
|
600mm
|
|
Travel (Y Axis)(mm)
|
900mm
|
|
Repeatability (X/Y/Z) (mm)
|
0.05mm
|
|
Max running speed
|
5m/min
|
|
Max feed-in height
|
110mm
|
|
Resolution ratio
|
0.025mm
|
|
Command language
|
HPGL,G Code*.u00*.mmg*.plt
|
|
Software operating environment
|
Windows98/2000/XP
|
|
Work mode
|
Stepping (rack transmission)
|
|
Spindle Motor Power(kW)
|
1.5KW/2.2KW
|
|
CNC or Not
|
CNC
|
|
Voltage
|
220V/380V 50-60hz
|
|
Dimension(L*W*H)
|
1300*1100*1450mm
|
|
Power (kW)
|
3
|
|
Weight (KG)
|
320
|
|
Warranty
|
1 Year
|
|
Key Selling Points
|
High-accuracy
|
|
Applicable Industries
|
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Retail, Printing Shops, Construction works , Energy & Mining, Other, Advertising Company
|
|
Machinery Test Report
|
Provided
|
|
Video outgoing-inspection
|
Provided
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
Bearing, Motor, Gear, Engine, Gearbox
|
|
Working area
|
600*900mm
|
|
spindle motor
|
1.5kw/2.2kw
|
|
cooling type
|
water-cooling
|
|
Spindle rotating speed
|
6000-24000rpm/min
|
|
Max feed-in height
|
110mm
|
|
Control system
|
NC Studio/DSP
|
|
Spindle
|
Water Cooling Spindle
|
|
Software
|
Ucancam / ArtCam/TYPE3
|
|
Guide rail
|
Taiwan HIWIN Square Rail
|
Sample show
