Lithium Ore Dryer Rotary Drum Dryer 4TPH 6TPH 7TPH 12TPH 14TPH
Lithium Ore Dryer
1.Product Introduction
The lithium ore dryer is a critical pretreatment equipment for processing raw lithium ore, designed to enhance ore grade by removing moisture and facilitate subsequent processing and transportation.
2.Application
Its applications are extensive, primarily covering the following fields:
-
Lithium Ore Pretreatment: Drying mined lithium ores (such as spodumene, lepidolite, etc.) to reduce their moisture content, creating conditions for subsequent processing steps like crushing, beneficiation, or roasting.
-
Intermediate drying for lithium battery materials: Drying intermediate products during the preparation of lithium battery cathode materials (e.g., lithium hydroxide, lithium oxide) to meet specific moisture content requirements for processing, forming, or pelletizing.
-
Adapting to Different Ore Characteristics: Based on the physicochemical properties of various lithium ores—such as high-lithium-content spodumene, multi-element-bearing lepidolite, or thermally stable orthoclase—appropriate dryer models can be selected to achieve efficient and safe drying operations.
3.Working Principle
The lithium ore dryer operates according to the fundamental principle of drying: by heating the material, moisture is vaporized and removed to obtain solid material with a specified moisture content.
4.Advantages
-
High-Quality Drying: Enables gentle, uniform drying to prevent localized overheating that could damage material structure or chemical properties, making it particularly suitable for temperature-sensitive lithium battery materials.
-
Enhanced Processing Efficiency and Intensity: Continuous operation design combined with technologies like fluidized beds ensures thorough agitation of granular materials, boosting drying capacity and production intensity.
-
Safety and Environmental Compliance: For materials potentially containing organic solvents or requiring contamination avoidance, closed-loop circulation designs prevent solvent leakage, ensuring operational safety and facilitating solvent recovery while meeting environmental standards.
-
High Adaptability: Suitable dryer models can be selected or customized based on material form (lumps, granules, slurries, etc.), heat sensitivity, and final product requirements, fulfilling the diverse drying needs across the lithium industry chain.
5.Technical Specifications
| Product Specs (m) | Capacity (T/H) | Main Motor Power (kW) | Main Motor Model | Main Gearbox Model | Ratio | Weight (T) |
| φ1.2×10m | 2.5 | 7.5 | Y160M-R3 | ZL50-16-1 | - | 13.5 |
| φ1.5×12m | 3.3 - 4.9 | 10 | Y160L-6B3 | JZQ500-III-2F | - | 18.9 |
| φ1.5×15m | 4 - 6 | 18.5 | Y200L-6 | JZQ500-III-2F | - | 21 |
| φ1.8×12m | 4 - 6 | 11 | Y200L-6 | ZQ50-16II-2 | 16.46 | 22.33 |
| φ2.2×12m | 7 - 12 | 18.5 | Y160L-6 | JZQ650-III | 31.5 | 37.6 |
| φ2.2×14m | 7 - 12 | 18.5 | Y160L-6 | JZQ750-III | 31.5 | 40 |
| φ2.2×16m | 12 | 30 | Y225M-6 | JZQ750-III | 31.5 | 45 |
| φ2.4×14m | 12 | 30 | Y250M-6 | JZQ750-III | 31.5 | 51 |
| φ2.4×18m | 10 - 13 | 37 | Y250M-6 | ZL85-13-1 | 27.16 | 54 |
| φ2.4×20m | 10 - 14 | 37 | Y250M-6 | ZL85-13-1 | 27.16 | 54.14 |
| φ3×20m | 25 | 55 | Y250M-4 | ZL100-16-1 | 41.52 | 78 |
| φ3×25m | 32 - 36 | 75 | YR280M-4 | ZL100-16-1 | 41.52 | 104.9 |
6.Our Solutions
