Modular Linear Filling Machine Food Grade Servo Liquid Filling Machine High Precision
Price:
5000USD-10000USD
MOQ:
1
Delivery Time:
10-15 working days
Brand:
Datang
Product Description
Automatic Tracking Type Linear Liquid Filling Machine
Product Overview
The DT-GS1000 Series Linear Tracking Filling Machine incorporates advanced dynamic tracking filling technology, offering compatibility across a wide filling range from 100ml to 5000ml. Its linear layout design makes it ideal for automated production lines with small to medium capacity requirements, adaptable to various fluid and semi-fluid materials. With straightforward operation and reliable performance, this machine serves as a core general-purpose filling solution for diverse application scenarios.
Core Performance Features
- Dynamic tracking filling enables synchronous operation during bottle movement without shutdown requirements, ensuring consistent production efficiency
- Wide 100ml-5000ml filling range with one-click parameter adjustment, providing strong compatibility with diverse bottle types
- High-precision metering with filling error ≤±1%, fully compliant with national metering specifications
- Photoelectric induction positioning system ensures "no bottle, no fill" operation and automatic error correction for bottle deviation
- Stepless speed regulation from 20 to 80 bottles per minute, adaptable to different production rhythms
- Modular structure design enables seamless integration with upstream and downstream production equipment
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DT-GS1000 |
| Power Supply Voltage | 220V |
| Air Pressure | 0.5-0.8 MPa |
| Power | ≈8kW |
| Filling Range | 100mL-5000mL |
| Filling Accuracy | ±1% |
| Filling Speed | ≈20-80 bottles/min |
| Overall Dimensions | ≈L4500*W1280*H1900 (mm) |
Product Gallery
Frequently Asked Questions
Q: Can the filling range of the equipment be adjusted freely?
A: Yes. Filling parameters within 100ml-5000ml can be adjusted via the touch screen with one click, no need to replace core components.
Q: Can irregular bottles be filled normally?
A: Yes. It can be adapted to round, square, irregular and other conventional bottle types by customizing guide parts.
Q: Can the filling speed be adjusted according to production needs?
A: Yes. The production capacity can be freely adjusted from 20 to 80 bottles per minute, adapting to production rhythms of different batches.
Q: Will incorrect filling occur when no bottle passes by?
A: The equipment is equipped with a high-precision photoelectric induction positioning system, which realizes no bottle no fill, and automatic shutdown for error correction when the bottle is deviated.
Q: What is the stable filling accuracy of the equipment?
A: Under rated working conditions, the filling error is stably ≤±1%, which complies with relevant national metering specifications.
Q: Can it be linked with upstream and downstream capping and labeling equipment?
A: Yes. The modular structure can be seamlessly docked with upstream and downstream equipment such as bottle unscramblers, capping machines and labeling machines to build a fully automatic production line.
Q: What is the power supply requirement of the equipment?
A: It adopts AC220V 50Hz general civil/industrial power supply, no separate wiring modification required.
Q: What are the air supply requirements for the equipment?
A: It requires a stable air supply pressure of 0.5-0.8MPa, which can be met by conventional factory air supply systems.
Q: Is the equipment difficult to operate?
A: It adopts touch screen intelligent control with a concise interface and visualized parameters. Ordinary operators can get started after simple training.
Q: What is the floor space of the equipment?
A: The overall dimension of the whole machine is 4500*1280*1900mm, with a linear layout, no need to reserve extra operating space.
