Astm B163 Incoloy 825 UNS N08825 925 Uns No 9925 Nickel Alloy Sch80 SchXXS Welded Seamless Pipe

astm b163 Incoloy 825 UNS N08825 925 uns no 9925 Nickel alloy sch80 schXXS welded seamless pipe / tube

• Inconel Alloy Series

incoloy 925 tube Features: nickel-chromium alloy with good oxidation resistance at higher temperatures, with good resistance in carburizing and chloride containing environments. Inconel 600 is a nickel-chromium alloy designed for use from cryogenic to elevated temperatures in the range of 2000 deg F(1093 deg C). The high nickel content of the alloy enables it to retain considerable resistance under reducing conditions and makes it resistant to corrosion by a number of organic and inorganic compounds. The nickel content gives it excellent resistance to chloride-ion stress-corrosion cracking and also provides excellent resistance to alkaline solutions. Alloy 600 is non-magnetic, has excellent mechanical properties and a combination of high strength and good workability and is readily weldable. Inconel 600 exhibits cold forming characteristics normally associated with chromium-nickel stainless steels.

• 1. Chemical Composition Requirement

  The Chemical Composition of Incoloy 925, %
  Nickel	42.0-46.0
  Chromium	19.5-22.5
  Iron	≥22.0
  Molybdenum	2.5-3.5
  Copper	1.5-3.0
  Titanium	1.9-2.4
  Alumium	0.1-0.5
  Manganese	≤1.00
  Silicon	≤0.50
  Niobium	≤0.50
  Carbon	≤0.03
  Sulfur	≤0.30

• 2. Mechanical Properties of Incoloy 925

  Tensile Strength, min.		Yield Strength, min.		Elongation, min.	Hardness, min.
  Mpa	ksi	Mpa	ksi	%	HRC
  1210	176	815	118	24	36.5

  3. Physical Properties of Incoloy 925

  Density	Melting Range		Specific Heat		Electrical Resistivity
  g/cm3	°F	°C	J/kg.k	Btu/lb. °F	µΩ·m
  8.08	2392-2490	1311-1366	435	0.104	1166

  4. Product Forms and Standards

  Product Form	Standard
  Rod, bar & Wire	ASTM B805
  Plate, sheet & strip	ASTM B872
  Seamless pipe and tube	ASTM B983
  Forging	ASTM B637
