22kW Fast Charging Wall-mounted EV Charging Station with 4G Remote Technology and Type 2 GB/T 32A Interface

[Key Features]

[Key Features]
Ultra-Fast 22kW Charging: Delivers up to 22kW of power (32A, 3-Phase), charging your EV up to 3x faster than standard 7kW chargers.
Universal Interchangeable Plugs: Includes CEE (Red/Blue), UK 3-Pin, and Schuko adapters. Switch power sources instantly to suit your location.
Smart Security (NFC/RFID): Protect your station from unauthorized use. Simply tap the included RFID card or NFC-enabled device to start/stop charging.
Interactive LCD Touch Screen: Real-time monitoring of voltage, current, power, temperature, and charging time. Touch buttons allow for Current Adjustment (6A-32A)

 and “Scheduled Charging”.
Rugged & Weatherproof: IP65 rated for water and dust resistance, with an IK10 impact-resistant shell, ensuring reliable operation in harsh outdoor environments.

[Comprehensive Safety Protection]
Your safety is our priority. The unit includes:
- Over-Voltage / Under-Voltage Protection
- Over-Load / Short-Circuit Protection
- Earth Leakage Protection (Type A + DC 6mA)
- Lightning & Surge Protection
- Emergency Stop Functionality

1.The EV Charger 7KW/22KW is a versatile and efficient AC home charging station ideal for fast charging electric vehicles.

2.Equipped with 32A adjustable rated current, the  model features over-voltage protection and is suitable for IEC 62196-2 (Type 2) charging standards.

3.The Wall Box EV Charger is made of high-quality ABS+PC materials, ensuring durability and safety in any environment.

4.With a compact design and easy installation process, this product is an excellent choice for businesses or individuals seeking reliable and convenient charging options.

5.ideal for those who value convenience and want to streamline the charging process.

Established in 2014, Shenzhen Huinengzhi Technology Co., Ltd. specializes in charging pile research and development. Our company's main expertise lies in the creation and innovation of charging technology and manufacturing of both AC and DC charging stations. We include the production of PCBA, as well as providing software and hardware development and customization services for our clients. We are committed to promoting green transportation initiatives and are ready to collaborate for mutual success. Connect with us to benefit from a complete portfolio of charging station products and services.

Q1. Who are we?

A: Our company " Shenzhen Huinengzhi Technology"

10+ Years Dedicated EV Charger Manufacturer (Established in 2014).

Over 1000 units deployed across Europe, South America, and Asia.

Independent Hardware and Software R&D with self-developed SECC controllers.

Q2. Do you test all your chargers before shipping?
A: All major components are tested before assembly and each charger is fully tested before shipped

Q3.what can you buy from us?
A: AC &DC EV charging pile

Q4. Can this 7kW charger be managed by a third-party white-label software platform?

A: Yes. With full OCPP 1.6J compliance, the charger allows operators to change the WebSocket URL via a local configuration web page or app, connecting instantly to any third-party CMS for billing, user authorization, and firmware OTA updates.

Q5: What are the installation requirements for a 7kW AC charging station?

A: A 7kW AC charger requires a single-phase 230V AC power supply with a current of 32A. It is highly recommended to install a dedicated circuit breaker (Type B RCD or Type A + DC 6mA protection) to ensure electrical safety.

Q6: Can a 7kW AC charger be installed at home?

A: Yes. A 7kW AC charger is the most popular choice for residential installations, as most household electrical grids can support a 32A single-phase load without requiring expensive grid upgrades.

Q7: Is a 7kW AC charger compatible with all electric vehicles?

A: Yes, it is compatible with almost all modern EVs and plug-in hybrids (PHEVs). However, the actual charging speed will be limited by the vehicle’s maximum onboard charger capacity (e.g., if a PHEV only accepts 3.5kW, it will charge at 3.5kW even when connected to a 7kW charger).

Q8: What charging interface standards do these chargers support?

A: Our charging stations can be configured with various global connector standards:

AC Charging: Type 2 (Europe), Type 1 (North America), GB/T (China).

DC Charging: CCS Combo 2 (Europe), CCS Combo 1 (North America), CHAdeMO (Japan), GB/T (China), and NACS (Tesla standard).

Q9: Are these chargers safe to use in the rain or extreme weather?

A: Yes. Our chargers are designed with high weatherproof ratings (typically IP54 or IP55 for outdoor use). They feature multiple safety protections, including over-current, over-voltage, short-circuit, leakage, and lightning protection.

Q10: Can I custom my LOGO?

Answer: Yes. You can not only custom LOGO, but also color, cable, enclosure box and carton. Just contact us if you have special needs. We accept full customization for Appearance/Software/Functions/ Accessories/Charging Standards/Packaging etc.

Q11: How long to fully charge a car?

To know how long to charge a car, you need to know the OBC(on board charger) power of the car, the car battery capacity, the charger power. The hours to fully charge a car =battery kw.h/obc or charger power the lower one. For e.g, the battery is 40kw.h,obc is 7kw, charger is 22kw, the 40/7=5.7hours. If the obc is 22kw, then 40/22=1.8hours.
