22kW Fast Charging EV Charger with Smart APP WIFI OCPP and Universal Compatibility for Electric Vehicle Charging Station
|
Parameter |
Specification |
|
Max Power |
22kW (3-Phase) |
|
Voltage |
400V AC ± 15% |
|
Current |
32A per phase |
|
Display |
4.3 inch LCD Touch Screen |
|
Connector |
Type 1 / Type 2/GBT |
|
Network |
4G / Ethernet / OCPP 1.6J |
|
Cable lemgth |
5 M (UL/TPU) |
|
Standard |
IEC 62196-2 IEC 61851-1 |
|
Protection |
IP54 / IK08 |
[Key Features]
Ultra-Fast 22kW Charging: Delivers up to 22kW of power (32A, 3-Phase), charging your EV up to 3x faster than standard 7kW chargers.
Universal Interchangeable Plugs: Includes CEE (Red/Blue), UK 3-Pin, and Schuko adapters. Switch power sources instantly to suit your location.
Smart Security (NFC/RFID): Protect your station from unauthorized use. Simply tap the included RFID card or NFC-enabled device to start/stop charging.
Interactive LCD Touch Screen: Real-time monitoring of voltage, current, power, temperature, and charging time. Touch buttons allow for Current Adjustment (6A-32A)
and “Scheduled Charging”.
Rugged & Weatherproof: IP65 rated for water and dust resistance, with an IK10 impact-resistant shell, ensuring reliable operation in harsh outdoor environments.
[Comprehensive Safety Protection]
Your safety is our priority. The unit includes:
- Over-Voltage / Under-Voltage Protection
- Over-Load / Short-Circuit Protection
- Earth Leakage Protection (Type A + DC 6mA)
- Lightning & Surge Protection
- Emergency Stop Functionality
1.22KW High Power Fast Charging Station: The EV Charger Electric Car Charger is a high powered fast charging station capable of delivering 22 KW of power to your electric vehicle. This rapid charging ability will significantly reduce your charging time, making it an ideal choice for those with a busy lifestyle.
2.Universal Compatibility: This car charger is designed to be universally compatible with various car models, making it an excellent replacement or repair option for your current charging system. It can be easily installed in your garage or workplace, providing a convenient and cost-effective solution for your charging needs.
3.Sturdy and Durable Construction: Constructed from high-quality plastic and metal materials, the EV Charger Electric Car Charger is built to last. Its strong and robust design ensures that it can withstand daily use, providing you with a dependable charging station that will serve you well for years to come.
4.Easy Installation and Maintenance: The EV Charger Electric Car Charger features a user-friendly design that makes installation and maintenance a breeze. With Neutral packing and 24-hour customer service, this charger can be quickly installed by any user, and any issues can be resolved swiftly and efficiently.
5.Environmentally Friendly: The EV Charger Electric Car Charger is designed with the environment in mind. It is a wall-mounted charger that is ideal for both indoor and outdoor use, and with its compact size and low energy consumption, it helps to reduce your carbon footprint and save you money on your energy bills.
Shenzhen Huinengzhi Technology Co., Ltd. specializes in charging pile research and development. With a focus on charging technology, PCBA production, and AC/DC charging station manufacturing, our company has been at the forefront of innovation since its establishment in 2014. We are committed to providing comprehensive charging station solutions and offer tailored software and hardware development services. We invite you to engage with us in a collaborative partnership, as we strive to meet the ever-evolving needs of the market.
Q1. Who are we?
A: Our company " Shenzhen Huinengzhi Technology"
10+ Years Dedicated EV Charger Manufacturer (Established in 2014).
Over 1000 units deployed across Europe, South America, and Asia.
Independent Hardware and Software R&D with self-developed SECC controllers.
Q2. Do you test all your chargers before shipping?
A: All major components are tested before assembly and each charger is fully tested before shipped
Q3.what can you buy from us?
A: AC &DC EV charging pile
Q4: What charging interface standards do these chargers support?
A: Our charging stations can be configured with various global connector standards:
AC Charging: Type 2 (Europe), Type 1 (North America), GB/T (China).
DC Charging: CCS Combo 2 (Europe), CCS Combo 1 (North America), CHAdeMO (Japan), GB/T (China), and NACS (Tesla standard).
Q5: Are these chargers safe to use in the rain or extreme weather?
A: Yes. Our chargers are designed with high weatherproof ratings (typically IP54 or IP55 for outdoor use). They feature multiple safety protections, including over-current, over-voltage, short-circuit, leakage, and lightning protection.
Q6: Can I custom my LOGO?
Answer: Yes. You can not only custom LOGO, but also color, cable, enclosure box and carton. Just contact us if you have special needs. We accept full customization for Appearance/Software/Functions/ Accessories/Charging Standards/Packaging etc.
Q7: What the MOQ for the product?
A: There is no MOQ request for normal charger. OEM MOQ depends the customers’ requirements and products’ features.
Q8: How long to fully charge a car?
To know how long to charge a car, you need to know the OBC(on board charger) power of the car, the car battery capacity, the charger power. The hours to fully charge a car =battery kw.h/obc or charger power the lower one. For e.g, the battery is 40kw.h,obc is 7kw, charger is 22kw, the 40/7=5.7hours. If the obc is 22kw, then 40/22=1.8hours.
