HORIZONTAL AND VERTICAL ROTARY TABLE
Price:
Negotiable
MOQ:
1
Delivery Time:
Negotiable
Product Description
| 号 Model |
T型沟槽 T Slot mm |
沟槽类型 Slot Type |
中心轴套 Center Sleeve |
蜗轮比 Worm gear Ratio |
立式承载力 Vertical Loading Kg |
卧式承载力 Horizontal Loading Kg |
重量 Weight kg |
| HV-150 | 11 | 3 section | MT-2 | 90︰1 | 20 | 39 | 13 |
| HV-200 | 13 | 6 section | MT-3 | 90︰1 | 44 | 87 | 29 |
| HV-250 | 13 | 6 section | MT-3 | 90︰1 | 62 | 123 | 41 |
| HV-300 | 16 | 6 section | MT-4 | 90︰1 | 98 | 195 | 65 |
| HV-350 | 16 | 6 section | MT-4 | 90︰1 | 147 | 294 | 98 |
| HV-400 | 16 | 6 section | MT-5 | 90︰1 | 195 | 390 | 130 |
| 型号 Model |
D | H | A | B | K |
| HV-150 | 150 | 92 | 220 | 160 | 18 |
| HV-200 | 200 | 120 | 310 | 225 | 18 |
| HV-250 | 250 | 120 | 320 | 280 | 18 |
| HV-300 | 300 | 140 | 410 | 325 | 18 |
| HV-350 | 350 | 140 | 460 | 380 | 18 |
| HV-400 | 400 | 140 | 510 | 435 | 18 |
