High Precision 5 Micron Stainless Steel Filter Screen SS316 / 316L For Dust Filtration
High-precision 5-micron SS316 / 316L stainless steel filter screen for dust filtration
stainless steel filter screen Description
Anping Chuangyi Hardware Products Co., Ltd. primarily manufactures high-precision stainless steel filter meshes. Our 316 and 316L stainless steel wire meshes are specifically designed for efficient dust filtration, dust collection, and particle separation in various industrial environments. Made from high-quality austenitic stainless steel, they possess excellent corrosion resistance, high-temperature resistance, structural stability, and high filtration accuracy, making them ideal filter materials for dust control systems.
With its rigorous weaving process and precise mesh size, this wire mesh ensures consistent and stable dust filtration performance. It effectively blocks dust particles, powder, and impurities while maintaining good air permeability and a long service life.
Parameter Table
| Products name | Stainless Steel Filter Screen |
| Material | 316 stainless steel, 316L stainless steel |
| Weave Type | Plain weave, twill weave, Dutch weave |
| Mesh Size | 1 mesh – 500 mesh (customizable) |
| Wire Diameter | 0.05mm – 2.0mm |
| Width | 0.05mm – 2.0mm |
| Length | 30m per roll (customizable) |
| Edge | Selvage edge, cut edge, reinforced edge |
|
Mesh/Inch |
Wire Diameter | Aperture | Open area | weigh(LB)100square foot | ||
|
Inch |
MM |
Inch |
MM |
|||
|
1×1 |
0.08 |
2.03 |
0.92 |
23.37 |
84.6 |
41.1 |
|
2×2 |
0.063 |
1.6 |
0.437 |
11.1 |
76.4 |
51.2 |
|
3×3 |
0.054 |
1.37 |
0.279 |
7.09 |
70.1 |
56.7 |
|
4×4 |
0.063 |
1.6 |
0.187 |
4.75 |
56 |
104.8 |
|
4×4 |
0.047 |
1.19 |
0.203 |
5.16 |
65.9 |
57.6 |
|
5×5 |
0.041 |
1.04 |
0.159 |
4.04 |
63.2 |
54.9 |
|
6×6 |
0.035 |
0.89 |
0.132 |
3.35 |
62.7 |
48.1 |
|
8×8 |
0.028 |
0.71 |
0.097 |
2.46 |
60.2 |
41.1 |
|
10×10 |
0.025 |
0.64 |
0.075 |
1.91 |
56.3 |
41.2 |
|
10×10 |
0.02 |
0.51 |
0.08 |
2.03 |
64 |
26.1 |
|
12×12 |
0.023 |
0.584 |
0.06 |
1.52 |
51.8 |
42.2 |
|
12×12 |
0.02 |
0.508 |
0.063 |
1.6 |
57.2 |
31.6 |
|
14×14 |
0.023 |
0.584 |
0.048 |
1.22 |
45.2 |
49.8 |
|
14×14 |
0.02 |
0.508 |
0.051 |
1.3 |
51 |
37.2 |
|
16×16 |
0.018 |
0.457 |
0.0445 |
1.13 |
50.7 |
34.5 |
|
18×18 |
0.017 |
0.432 |
0.0386 |
0.98 |
48.3 |
34.8 |
|
20×20 |
0.02 |
0.508 |
0.03 |
0.76 |
36 |
55.2 |
|
20×20 |
0.016 |
0.406 |
0.034 |
0.86 |
46.2 |
34.4 |
|
24×24 |
0.014 |
0.356 |
0.0277 |
0.7 |
44.2 |
31.8 |
|
30×30 |
0.013 |
0.33 |
0.0203 |
0.52 |
37.1 |
34.8 |
|
30×30 |
0.012 |
0.305 |
0.0213 |
0.54 |
40.8 |
29.4 |
|
30×30 |
0.009 |
0.229 |
0.0243 |
0.62 |
53.1 |
16.1 |
|
35×35 |
0.011 |
0.279 |
0.0176 |
0.45 |
37.9 |
29 |
|
40×40 |
0.01 |
0.254 |
0.015 |
0.38 |
36 |
27.6 |
|
50×50 |
0.009 |
0.229 |
0.011 |
0.28 |
30.3 |
28.4 |
|
50×50 |
0.008 |
0.203 |
0.012 |
0.31 |
36 |
22.1 |
|
60×60 |
0.0075 |
0.191 |
0.0092 |
0.23 |
30.5 |
23.7 |
|
60×60 |
0.007 |
0.178 |
0.0097 |
0.25 |
33.9 |
20.4 |
|
70×70 |
0.0065 |
0.165 |
0.0078 |
0.2 |
29.8 |
20.8 |
|
80×80 |
0.0065 |
0.165 |
0.006 |
0.15 |
23 |
23.2 |
|
80×80 |
0.0055 |
0.14 |
0.007 |
0.18 |
31.4 |
16.9 |
|
90×90 |
0.005 |
0.127 |
0.0061 |
0.16 |
30.1 |
15.8 |
|
100×100 |
0.0045 |
0.114 |
0.0055 |
0.14 |
30.3 |
14.2 |
|
100×100 |
0.004 |
0.102 |
0.006 |
0.15 |
36 |
11 |
|
100×100 |
0.0035 |
0.089 |
0.0065 |
0.17 |
42.3 |
8.3 |
|
110×110 |
0.004 |
0.1016 |
0.0051 |
0.1295 |
30.7 |
12.4 |
|
120×120 |
0.0037 |
0.094 |
0.0064 |
0.1168 |
30.7 |
11.6 |
|
150×150 |
0.0026 |
0.066 |
0.0041 |
0.1041 |
37.4 |
7.1 |
|
160×160 |
0.0025 |
0.0635 |
0.0038 |
0.0965 |
36.4 |
5.94 |
|
180×180 |
0.0023 |
0.0584 |
0.0033 |
0.0838 |
34.7 |
6.7 |
|
200×200 |
0.0021 |
0.0533 |
0.0029 |
0.0737 |
33.6 |
6.2 |
|
250×250 |
0.0016 |
0.0406 |
0.0024 |
0.061 |
36 |
4.4 |
|
270×270 |
0.0016 |
0.0406 |
0.0021 |
0.0533 |
32.2 |
4.7 |
|
300×300 |
0.0051 |
0.0381 |
0.0018 |
0.0457 |
29.7 |
3.04 |
|
325×325 |
0.0014 |
0.0356 |
0.0017 |
0.0432 |
30 |
4.4 |
|
400×400 |
0.001 |
0.0254 |
0.0015 |
0.037 |
36 |
3.3 |
|
500×500 |
0.001 |
0.0254 |
0.001 |
0.0354 |
25 |
3.8 |
|
635×635 |
0.0008 |
0.0203 |
0.0008 |
0.0203 |
25 |
2.63 |
Main Applications
• Industrial dust collection systems and filter elements
• Powder filtration, particle screening and separation
• Environmental protection equipment, flue gas dust removal
• Pharmaceutical powder filtration and food dust control
• Chemical industry dust filtration and exhaust gas treatment
• Air purification, ventilation and dust collection systems
• Filter elements for dust collectors, vacuum cleaners and industrial hoods
If you need high-precision 316/316L stainless steel wire mesh for dust collection, please contact us. We will provide you with customized solutions and highly competitive quotes.
