6.0mm Extra Thick Wire Stainless Steel Rope Net For Industrial And Mine Safety
6.0mm Extra Thick Wire Stainless Steel Rope Net for Industrial and Mine Safety
Stainless Steel Rope Net Description
Features and Advantages
1. Ultra-high load-bearing capacity: Utilizing a 6.0mm thickened steel wire rope design, the single rope breaking force reaches up to 22kN, far exceeding traditional rope nets, capable of withstanding heavy impacts and drop pressure without deformation or breakage.
2. Extreme Environment Adaptability: Constructed with 316/316L stainless steel, offering excellent wear resistance, corrosion resistance, and aging resistance. Suitable for mining areas, dusty, humid, and mildly corrosive industrial workshops, as well as outdoor port environments.
3. Reinforced Connection Structure: Employs precision-reinforced sleeves for secure connections, preventing loosening due to long-term vibration and impact, ensuring overall structural stability.
4. Long Service Life and High Cost-Effectiveness: Utilizes industrial-grade thickened materials, offering impact resistance, wear resistance, and tear resistance. With a service life exceeding 30 years, it eliminates the need for frequent replacements, significantly reducing engineering maintenance costs.
5. High Safety and Stability: Non-flammable, anti-static, and resistant to rust and embrittlement, it maintains stable performance in harsh environments, posing no potential safety hazards and meeting international industrial and mining safety standards.
6. Flexible Customization: Supports customized mesh sizes, overall dimensions, and edge reinforcement methods to adapt to the installation needs of various industrial and mining sites.
| Material | SUS316/SUS316L stainless steel (7×19 high-strength steel wire rope) |
| Wire Diameter | 6.0mm thickened |
| Mesh Size | 75×75mm (customizable) |
| Connection Method | Precision pressed sleeve (reinforced) |
| Tensile Strength | ≥1800MPa |
| Single Rope Breaking Force | ≥22kN |
| Operating Temperature Range | -50℃~+600℃ |
| Salt Spray Resistance | ≥1800 hours (316L grade) |
| Surface Treatment | Passivated polishing |
| Structure | Heavy-duty woven and fixed integrated structure |
| Code | Rope construction | Rope diameter |
Aperture |
Min breaking load | ||
|
Inch |
Mm |
Inch |
Mm |
(Ibs) |
||
|
SW-01 |
7×7 |
1/8 |
3.2 |
2×2 |
51×51 |
1600 |
|
SW-02 |
7×7 |
3/32 |
2.4 |
4×4 |
102×102 |
920 |
|
SW-03 |
7×7 |
3/32 |
2.4 |
3×3 |
76×76 |
920 |
|
SW-04 |
7×7 |
3/32 |
2.4 |
2×2 |
51×51 |
920 |
|
SW-05 |
7×7 |
5/64 |
2.0 |
3×3 |
76×76 |
676 |
|
SW-06 |
7×7 |
5/64 |
2.0 |
2×2 |
51×51 |
676 |
|
SW-07 |
7×7 |
5/64 |
2.0 |
1.5×1.5 |
38×38 |
676 |
|
SW-08 |
7×7 |
1/16 |
1.6 |
3×3 |
76×76 |
504 |
|
SW-09 |
7×7 |
1/16 |
1.6 |
2×2 |
51×51 |
504 |
|
SW-10 |
7×7 |
1/16 |
1.6 |
1.5×1.5 |
38×38 |
504 |
|
SW-11 |
7×7 |
1/16 |
1.6 |
1×1 |
25×25 |
504 |
|
SW-12 |
7×7 |
3/64 |
1.2 |
2×2 |
51×51 |
606 |
|
SW-13 |
7×7 |
3/64 |
1.2 |
1.5×1.5 |
38×38 |
306 |
|
SW-14 |
7×7 |
3/64 |
1.2 |
1×1 |
25×25 |
306 |
|
SW-15 |
7×7 |
3/64 |
1.2 |
4/5×4/5 |
20×20 |
306 |
|
SW-16 |
7×19 |
1/8 |
3.2 |
4×4 |
102×102 |
1600 |
|
SW-17 |
7×19 |
1/8 |
3.2 |
3×3 |
76×76 |
1600 |
|
SW-18 |
7×19 |
1/8 |
3.2 |
2×2 |
51×51 |
1600 |
Product Applications
• Rockfall Protection Netting for Mine Slopes
• Safety Barriers for Mine Tunnels and Roads
• Protective Fences for Heavy Machinery and Equipment
• Heavy Cargo Isolation Netting for Ports and Docks
• Fall Protection Netting for Industrial Workshops
• Safety Enclosures for Quarries and Mines
• Heavy-Duty Fall Protection Netting for Construction Projects
• High-Strength Safety Isolation Netting for Metallurgical Industrial Zones
• Protective Netting for Port Cranes and Lifting Equipment
• Safety Barriers for Mine Waste Rock Piles
