0.6/1KV Mitul Cores (5C) CU Conductor PVC insulated LV Power Cable(Unarmoured)（CU/PVC/XLPE/NYY/N2XY)

0.6/1KV Mitul Cores (5C) CU Conductor PVC insulated Power Cable(Unarmoured)(CU/PVC/XLPE/NYY/N2XY)

1.Quick Details:
Place of Origin: Henan, China (Mainland)
Brand Name: ZHENGLAN
Insulation Material:MgO
Type:Low Voltage
Application:Construction
Conductor Material:Copper
Jacket:LSZH
Certificate:CCC/ISO/CE
Conductor:Copper Core
Insulation:Magnesium oxide
Rated voltage:450/750V
Product name:Mineral insulated cable
Standard:IEC60502
Core:Multi-core
Packing: packed in wooden drum or steel-wooden drum or as your request;

Special Characteristics

1. Fire resistant: neither burn or support combustion., comply with the requirements of IEC 60331 and BS 6387.
2. High operation temperature: continuous operating temperature up to 250 °C, and for short periods up to approaching the melting point of copper 1083 °C.
3. Inherent flameproof barrier: with a non-flammable sheath the high compacted insulation will resist the transmission of vapors, gases or flames.
4. High mechanical strength: Really robust and can withstand a considerable amount of stresses such as, twisting, bending and flattening.
5. Pliable: fully annealed and extremely ductile and easily manipulated to follow existing wiring routes and irregular shapes.
6. Non-ageing, Integral earth continuity, Small overall diameter
7. Waterproof, Corrosion resistant, Radiation resistant
8. Excellent electric shielding, Easy installation, Long service life
