Single Core Insulated Cable 0.6/1KV Low Voltage ( Armoured ) , PVC Insulated CableIEC 60502-1, IEC 60228
Single Core Insulated Cable/ 0.6/1KV Low Voltage (Armoured) , PVC Insulated Cable
Description:
0.6/1KV PVC Insulated Cables (Armoured)
IEC60502,IEC60228,GB/T 12706.1-2008
CE,CCC,KEMA,ISO
Application:
These cables are used for electricity supply in low voltage installation system, They are suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage.
Standard:
Basic design to IEC 60502-1, IEC 60228,BS EN 60228
China: GB/T 12706.2-2008
Other standards such as BS7870,DIN and ICEA upon request
Certificates:
CE, ROHS,KEMA and more others at request
Cable Parameters:
Single Core Power Cable (Armoured)
|
Nominal Area |
Approx Conductor Diameter |
Nominal Insulation thickness |
Nominal bedding thickness |
Nominal Alum Wire dia. |
Nominal Sheath thickness |
Approx. Overall Diameter |
Approx. Weight |
| mm2 | mm | mm | mm | mm | mm | mm | Kg/Km |
| 1x10 | 4 | 1.0 | 1.0 | 0.8 | 1.8 | 14 | 300 |
| 1x16 | 5 | 1.0 | 1.0 | 0.8 | 1.8 | 15 | 375 |
| 1x25 | 6.3 | 1.2 | 1.0 | 0.8 | 1.8 | 16 | 500 |
| 1x35 | 7.4 | 1.2 | 1.0 | 0.8 | 1.8 | 18 | 625 |
| 1x50 | 8.8 | 1.4 | 1.0 | 1.25 | 1.8 | 20 | 835 |
| 1x70 | 10.6 | 1.4 | 1.0 | 1.25 | 1.8 | 22 | 1075 |
| 1x95 | 12.4 | 1.6 | 1.0 | 1.25 | 1.8 | 24 | 1385 |
| 1x120 | 14.0 | 1.6 | 1.0 | 1.6 | 1.8 | 26 | 1700 |
| 1x150 | 15.5 | 1.8 | 1.0 | 1.6 | 1.8 | 28 | 2025 |
| 1x185 | 17.4 | 2.0 | 1.0 | 1.6 | 1.8 | 31 | 2450 |
| 1x240 | 20.3 | 2.2 | 1.0 | 1.6 | 1.9 | 34 | 3100 |
| 1x300 | 22.7 | 2.4 | 1.0 | 2.0 | 2.0 | 38 | 3900 |
| 1x400 | 25.4 | 2.6 | 1.2 | 2.0 | 2.1 | 42 | 4875 |
| 1x500 | 28.8 | 2.8 | 1.2 | 2.0 | 2.2 | 45 | 6050 |
| 1x630 | 30.4 | 2.8 | 1.2 | 2.0 | 2.4 | 50 | 7625 |
