Low Voltage NA2XY CU Cable Single Core Copper Cable Xlpe Insulated Underground Cable
Low voltage NA2XY CU Cable single core copper cable xlpe insulated underground cable unarmored
Application:
Construction:
Conductor type:Class 2 as per IEC 60228, BS EN 60228 can also be supplied upon request.
Insulation type: XLPE material and thickness shall be as per IEC 60502 or BS 5467 rated for 90°C continuous operation.
Outer Sheath: Outer sheath shall be of Extruded PVC Type ST2 as per IEC 60502-1 or Type 9 as BS 6346/5467.
Special type of PVC sheathing material such as flame retardant, Fire Resistant PVC, Anti-Termite PVC, Anti-Rodent PVC, Sunlight resistant PVC, Oil Resistant PVC are available on special request. Also, special sheathing materials such as PE are available on request.
Characteristics:
1.The long-term permissible operation temperature of the conductor shall not be higher than 90℃.
2. Conductor maximum short circuit((less than 5 second) temperature shall not be higher than 160℃.
3. The cable is not limited by drop in level when being laid, and the environment temperature shall not be lower than 0℃.
4. Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents, and flame retardance.
5. Light weight, perfect bending properties, installed and maintained easily and conveniently.
Low voltage NA2XY CU Cable single core copper cable xlpe insulated underground cable unarmored Parameters Table:
| Conductor dimensions (mm2) | Insulation thickness (mm) | Nonmetallic sheath, unarmored | ||
| Sheath thickness(mm) | Outer diameter approx.(mm) | Cable weight (Kg/km) | ||
| 1.5 | 0.7 | 1.4 | 5.6 | 45 |
| 2.5 | 0.7 | 1.4 | 6 | 57 |
| 4 | 0.7 | 1.4 | 6.5 | 75 |
| 6 | 0.7 | 1.4 | 7 | 97 |
| 10 | 0.7 | 1.4 | 8.1 | 143 |
| 16 | 0.7 | 1.4 | 9.2 | 206 |
| 25 | 0.9 | 1.4 | 10.6 | 303 |
| 35 | 0.9 | 1.4 | 11.8 | 403 |
| 50 | 1 | 1.4 | 13.2 | 554 |
| 70 | 1.1 | 1.4 | 15 | 755 |
| 95 | 1.1 | 1.5 | 16.9 | 1004 |
| 120 | 1.2 | 1.5 | 18.5 | 1250 |
| 150 | 1.4 | 1.6 | 20.6 | 1558 |
| 185 | 1.6 | 1.6 | 22.7 | 1908 |
| 240 | 1.7 | 1.7 | 25.3 | 2450 |
| 300 | 1.8 | 1.8 | 27.9 | 3043 |
| 400 | 2 | 1.9 | 31.6 | 4021 |
| 500 | 2.2 | 2 | 35 | 5002 |
Low voltage NA2XY CU Cable single core copper cable xlpe insulated underground cable unarmored Products show:
Why Choose Zhenglan Cable:
- OEM/ODM services provided
- Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted
- Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007
- Registered capital of $30 million and factory covers an area of 60,000㎡
- Advanced test equipment and procedures, 100% inspection before factory
- Enough stocks and the higest efficient shipping time guarranteed
- Professional pre-sales and after-sales services provided
