Excellent Conductivity Power Transmission Line Conductor Cable AAAC Factory Supply with AS 1531 Standard
Product Description:
All-aluminum alloy conductor is a concentric stranded conductor made of aluminum alloy wire, typically 6201-T81 aluminum alloy wire, and can be made into single-layer or multi-layer structures depending on the requirements.
Applications:
AAAC are mainly used for overhead lines, in transmission and distribution electrical networks, having relatively long spans. It has a high tensile strength, good corrosion resistance, light weight, and comparable current-carrying capacity. They are also used as a messenger to support overhead
Standards:
ASTM B 399/B 399M, IEC 61089, BS EN 50182, AS 1531, DIN 4820, BS EN 50183, BS 3242, NF C 34-125, GB/T 1179
Conductor:
Hard-drawn aluminum alloy wire 6201
Technical Parameters:
| Code Name |
Area | Equiv.Aluminium Area | No.Dia of Wires | Approx. Overall Dia. |
Approx. Weight |
Breaking Load |
Max. DC Resistance at 20℃ |
| mm2 | mm2 | No./mm | mm | kg/km | kN | Ω/km | |
| Diamond | 34.36 | 29.3 | 7/2.50 | 7.5 | 94.3 | 9.64 | 0.967 |
| Dolomite | 41.58 | 35.4 | 7/2.75 | 8.25 | 113 | 11.6 | 0.799 |
| Emerald | 49.48 | 42.2 | 7/3.00 | 9 | 135 | 13.9 | 0.671 |
| Garnet | 77.28 | 65.8 | 7/3.75 | 11.3 | 211 | 21.7 | 0.43 |
| Jade | 111.3 | 94.8 | 7/4.50 | 13.5 | 304 | 31.2 | 0.298 |
| Jasper | 124 | 106 | 7/4.75 | 14.3 | 339 | 34.8 | 0.268 |
| Opal | 157.6 | 134 | 19/3.25 | 16.3 | 433 | 44.2 | 0.212 |
| Patronite | 182.8 | 155 | 19/3.50 | 17.5 | 503 | 51.3 | 0.183 |
| Pearl | 209.8 | 178 | 19/3.75 | 18.8 | 576 | 58.8 | 0.159 |
| Ruby | 261.6 | 221 | 37/3.00 | 21 | 721 | 73.5 | 0.128 |
| Ruthenium | 307 | 260 | 37/3.25 | 22.8 | 845 | 86.1 | 0.109 |
| Rutile | 336.7 | 285 | 19/4.75 | 23.8 | 924 | 94.4 | 0.0991 |
| Sapphire | 408.5 | 345 | 37/3.75 | 26.3 | 1120 | 115 | 0.0819 |
| Spinel | 506.1 | 427 | 61/3.25 | 29.3 | 1400 | 135 | 0.0662 |
| Tantalum | 586.9 | 495 | 61/3.50 | 31.5 | 1620 | 156 | 0.0572 |
| Topaz | 673.4 | 568 | 61/3.75 | 33.8 | 1860 | 179 | 0.0498 |
Drawing:
FAQ:
Q1: What is the brand name of the Bare Aluminum Conductor?
A1: The brand name of the Bare Aluminum Conductor is Zhenglan Cable.
Q2: What model number is designated for this Bare Aluminum Conductor?
A2: The model number for this product is All Aluminium Alloy Conductors (AAAC).
Q3: Where is the Bare Aluminum Conductor manufactured?
A3: The Bare Aluminum Conductor is made in China.
Q4: What are the main applications of the All Aluminium Alloy Conductors (AAAC)?
A4: The AAAC is commonly used for overhead power transmission and distribution lines due to its high strength and excellent conductivity.
Q5: What are the key advantages of using AAAC over traditional aluminum conductors?
A5: AAAC offers higher tensile strength, better corrosion resistance, and improved conductivity compared to traditional aluminum conductors, making it suitable for long-span installations.
