3+1 Cores Low Voltage Power Cable with Steel Tape Armor and XLPE Insulation for Underground Installation 3x150+70mm²
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
H1XDV-AS Cable LV Aluminum Power Cable 1KV STA Armored Aluminum Cable
NF C33-210/IEC60502-1 compliant aluminum power cables designed for underground power distribution in fixed installations, both indoors and outdoors, buried or concreted in environments with higher risk of mechanical damage.
Construction & Features
- Conductor: Class 1 solid or Class 2 stranded aluminum - round or sectorial shaped
- Insulation: Cross-Linked Polyethylene (XLPE)
- Armour: Steel tape armour (STA)
- Outer Sheath: Polyvinyl Chloride (PVC)
- UV-resistant black PVC outer sheath
- Operating temperature: -15°C to +90°C
H1XDV-AS low voltage industrial power cables feature steel tape armour that provides additional mechanical protection, making them suitable for fixed installation directly in concrete walls or buried underground in compliance with local building regulations. The steel tape armour offers lighter-duty protection compared to steel wire armour while adding less weight and bulk to the overall cable.
3+1 Cores Low Voltage Power Cable with Steel Tape Armor and XLPE Insulation for Underground Installation 3x150+70mm² Technical Specifications
| Cable Section | Nominal Thickness Insulation (mm) | Armour Thickness (mm) | Nominal Thickness of Sheath (mm) | Approx Overall Diameter (mm) | Max. DC-resist Conductor 20℃ (Ω/km) |
|---|---|---|---|---|---|
| 3x150+70mm² | Phase line: 1.4mm; Null line: 1.1mm | 0.5 | 2.5 | 43.8 | 0.206 |
Manufacturer Information
Zhenglan Cable Technology Co., Ltd is a professional cable and wire manufacturer with over 20 years of experience. Our 60,000 square meter factory is located in Wuzhi County, Jiaozuo City, Henan Province, China.
Product Range
- Overhead transmission line bare conductors (ACSR, AAC, AAAC)
- 1-35kV overhead transmission line insulated conductors
- 0.6/1kV, 1.8/3kV PVC/XLPE/PE insulated LV power cables
- 3.6/6kV to 26/35kV XLPE insulated MV power cables
- 300/300V to 450/750V control cables and house wires
Frequently Asked Questions
Is your company a factory or a trade company?
We are a factory with more than 20 years of manufacturing experience in China.
We are a factory with more than 20 years of manufacturing experience in China.
How long can I expect to get the sample?
Samples are ready for delivery in 3-7 days after payment confirmation. Delivery takes 3-7 days via express service.
Samples are ready for delivery in 3-7 days after payment confirmation. Delivery takes 3-7 days via express service.
What are your payment terms?
Standard terms: T/T 30% deposit, 70% balance before delivery. Trade assurance and other payment methods available.
Standard terms: T/T 30% deposit, 70% balance before delivery. Trade assurance and other payment methods available.
What's the delivery time?
Sample orders: 3-5 days. Formal orders: 7-30 days after payment, depending on quantity.
Sample orders: 3-5 days. Formal orders: 7-30 days after payment, depending on quantity.
What is your MOQ?
Minimum order quantity is typically 500 meters.
Minimum order quantity is typically 500 meters.
