1600W Invertor Solar Off Grid Inverter For Home Use 220VAC 110VAC

Price Negotiable

Price: $200-$500

MOQ: 1

Delivery Time: Negotiable

Brand: /

Product Description

1.6kW Off-Grid Solar Inverter for Home Energy Storage System

Product Highlights

Pure Sine Wave Output, Compatible with Various Loads - Utilizes ultra-high frequency technology for pure sine wave output, providing stable and interference-free power supply that safely drives refrigerators, air conditioners, precision electrical appliances and other equipment
Intelligent MPPT Control, Improved PV Utilization - Integrates high-precision MPPT solar controller with working voltage range of 30-450VDC and maximum PV open-circuit voltage of 500VDC, significantly enhancing solar panel power generation efficiency
Compatible with Multiple Battery Types - Flexible energy storage configuration options
Wall-mounted Design, Easy and Safe Installation - Lightweight body with wall-mounted structure for easy installation and transportation; equipped with non-power-off parallel machine auxiliary function for safer installation

Application Scenarios

Suitable for small household PV systems to achieve self-consumption and surplus power storage, reducing reliance on mains power
Supplies power to small household appliances and lighting equipment in remote areas such as villages and mountainous regions with inconvenient mains power access
Used as emergency power supply for households and small shops to ensure operation of critical equipment during mains power failures

Others

Factory Direct Supply - Own production base with direct order processing to ensure supply efficiency
Flexible Production Capacity - Support for small batch trial orders (MOQ 1 unit)
Customization Service - Product parameters (such as voltage, interface) can be customized according to customer requirements

Model		CH-ED2012EMH
AC Input	AC Input Voltage	220VAC (standard) / 110VAC (Custom)
	Input Voltage Range	90~280VAC±3V( Normal Mode) 170~280VAC±3V( UPS Mode)
	Input Frequency	50/60Hz±5%
	Rated Output Power (Battery Mode)	1600W
Output	Rated Output Power (PV Mode)	1600W
	Output Voltage	220/230/240VAC±5%
	Output Frequency	50/60Hz±0.1%
	Output Wave	Pure Sine Wave
	Transfer Time	≤10ms(UPS)/≤20ms(INV)
	Peak Power	3200VA
	Overload Ability	Battery Mode:1ls@105%-150% Load 2s@150%-200% Load 400ms@200% Load
Battery	Rated Voltage	12Vdc
	Constant Charging Voltage (Adjustable)	14.1Vdc
	Float Charging Voltage (Adjustable)	13.5Vdc
Charger	PV Charging Mode	MPPT
	Max PV Input Power	2000W
	MPPT Input Voltage Range	30-500Vdc
	Optimal Vmp Range	300-400Vdc
	Max PV Input Voltage	500Vdc
	Max PV Input Current	13A
	Max PV Charging Current	100A
	Max AC Charging Current	60A
	Max Charging Current	100A
Display	LCD Interface	can display operating mode/load/input/output
Interface	RS232	2400 Baud Rate 2400
	Expansion Slot Communication Interface	Lithium Battery BMS Communication Card, WIFI/Pitch2.54mm
	parallel interface	Not support Parallel
Ambient Temperature	Operating Temperature	-10°C-50°C
	Operating Humidity	-10°C-60°C
	Storage Temperature	20%-90% Non Condensing
	Noise	≤50dB
