48Vdc Grid Tied House Solar Inverter 6200W Pure Sine Wave Inverter
Price:
$300-500
MOQ:
1
Delivery Time:
Negotiable
Product Description
6200W Solar Inverter – Pure Sine Wave with MPPT Controller, Grid-Tied Support for Home & Commercial Use
Product Description
- Wide PV Input Voltage Range – Supports 60–500VDC input, compatible with various solar panel configurations for enhanced application adaptability
- External WiFi Module – Enables remote monitoring and control through wireless networks
- High Conversion Efficiency – Delivers up to 98% peak efficiency with minimal power loss, optimizing photovoltaic system performance
- Multiple Battery Type Compatibility – Supports lithium battery BMS communication, flexible energy storage system configurations to meet diverse application requirements
- Sturdy & Compact Structure – Lightweight, slim body design for easy installation and space efficiency
- Pure Sine Wave Output – 6200W rated power, 12400VA peak power, suitable for air conditioners, pumps, refrigerators, and other inductive loads
Product Features
- Low No-Load Loss: Lower than high-frequency machines with the same power rate
- Pure Sine Wave Output: Suitable for different loads
- Adjustable Parameters: Multiple parameters can be adjusted according to user needs
- Slim Body: Convenient installation and transportation
- Battery Reverse Connection Protection with Fuse-Free Switch: Safer installation
- Built-in MPPT Solar Controller
- High Output Voltage Precision: Take care of your appliances
- WiFi / Lithium Battery BMS Communication Support
| Model | CH—ED6248EMH | |
| AC Input | AC Input Voltage | 220VAC (Standard) / 110VAC (Custom) |
| Input Voltage Range | 90~280VAC±3V(Normal Mode) 170~280VAC±3V(UPS Mode) |
|
| Input Frequency | 50/60Hz±5% | |
| Rated Output Power (Battery Mode) | 6200W | |
| Output | Rated Output Power (PV Mode) | 6200W |
| Output Voltage | 220/230/240VAC±5% | |
| Output Frequency | 50/60Hz±0.1% | |
| Output Wave | Pure Sine Wave | |
| Transfer Time | ≤10ms(UPS Mode)/≤20ms(INV Mode) | |
| Peak Power | 12400VA | |
| Overload Ability | Battery Mode:1ls@105%-150% Load 2s@150%-200% Load 400ms@200% Load |
|
| Grid-connected Operation | Output Voltage | 220/23024VVAC |
| Grid-Tied Voltage Range | 170-265VAC | |
| Grid-Tied Frequency Range | 49-51±Hz/59-61±Hz | |
| Rated Output Curren | 26.9A | |
| Power Factor Range | >0.99 | |
| Peak Efficiency (DC/AC) | 98% | |
| Battery | Rated Voltage | 48Vdc |
| Constant Charging Voltage (Adjustable) | 56.4Vdc | |
| Float Charging Voltage (Adjustable) | 54Vdc | |
| Charger | PV Charging Mode | MPPT |
| Max PV Input Power | 6200W | |
| MPPT Input Voltage Range | 60-500Vdc | |
| Optimal VMP Range | 400-400Vdc | |
| Max PV Input Voltage | 500Vdc | |
| Max PV Input Current | 18A | |
| Max PV Charging Current | 120A | |
| Max AC Charging Current | 100A | |
| Max Charging Current | 120A | |
| Display | LCD Interface | Can display operating mode/load/input/output |
| Interface | RS232 | Baud Rate 2400 |
| Expansion Slot Communication Interface | Lithium Battery BMS Communication Card, WIFI/Pitch2.54mm | |
| Parallel Interface / Parallel Port | Not support Parallel | |
| Ambient Temperature | Operating Temperature | -10°C-50°C |
| Operating Humidity | -10°C-60°C | |
| Storage Temperature | 20%-90% Non Condensing | |
| Noise | ≤50dB | |
