2.56kWh 25.6V 100Ah LiFePO4 Battery Server Rack Battery 5000 Cycles
This high-performance rack-mounted lithium battery utilizes premium LiFePO₄ cells with an advanced Battery Management System (BMS). Designed to function as both an independent DC power supply and a modular building block for scalable energy storage systems, it delivers exceptional reliability and extended service life. Perfect for communication base stations, data centers, residential energy storage, and industrial applications, it seamlessly integrates with UPS systems and photovoltaic power generation equipment.
- Compact Size & Light Weight: Minimal space requirements with easy transportation and installation for diverse applications
- LED Direct Inverter Communication: Built-in display enables real-time monitoring and enhanced system coordination
- Ultra-long Cycle Life: Exceeds 5000 cycles at standard usage, ensuring durability and reduced long-term costs
- Multi-unit Parallel & Easy Expansion: Automatic addressing supports flexible capacity expansion without manual configuration
- Simple Installation & Easy Maintenance: Streamlined deployment process with convenient operation and maintenance
Communication base station backup power, data center backup power, residential energy storage systems, industrial energy storage solutions. Compatible with UPS systems and photovoltaic power generation equipment.
| Model | CH--GBP24-100R |
|---|---|
| Nominal Voltage (V) | 25.6 |
| Cell Specification | 100 |
| Nominal Capacity (Ah) | 100 |
| Nominal Energy (kWh) | 2.56 |
| Operating Voltage Range (V) | 22.4~29.2 |
| Recommended Charging Voltage (V) | 27.6 |
| Recommended Discharge Cut-off Voltage (V) | 24 |
| Standard Charge/Discharge Current (A) | 0.5C |
| Maximum Continuous Charge/Discharge Current (A) | 1C (Customizable) |
| Operating Temperature (°C) | -30~60 (Recommend 10~35) |
| Allowable Humidity Range (%RH) | <85 |
| Storage Temperature (°C) | -20~65 (Recommend 10~35) |
| Charging Temperature (°C) | 0~55 |
| Discharging Temperature (°C) | -10~55 |
| Protection Level | IP20 |
| Cooling Method | Natural Air Cooling / Intelligent Fan |
| Cycle Life | 5000+ Times at 80% DOD |
| Maximum Dimension (D*W*H) mm | 689*495*162 |
| Weight (kg) | 28 |
