High Intensity UV Lamps Uv Disinfection Unit PLC For Odor Removal

This UV disinfection device uses high-quality UV lamps with stable light efficiency, long service life, and continuous high-intensity ultraviolet radiation. The device employs a flow-through design, ensuring even water flow through the chamber and thorough irradiation without dead zones. No chemicals are required, it does not alter the water's physicochemical properties, and it produces no odors or byproducts. It is suitable for applications with stringent water quality requirements, such as municipal water supply, direct drinking water systems, and food processing water.

The UV Photolysis Odor Control System is an advanced environmental equipment that utilizes high-energy ultraviolet photolysis and photocatalytic oxidation technology to efficiently remove odorous gases (such as hydrogen sulfide, ammonia, methyl mercaptan, VOCs, etc.). When odorous gases pass through the UV photolysis chamber, the 185nm and 254nm ultraviolet photons emitted by high-energy UV lamps directly break the chemical bonds of gas molecules, decomposing large molecular pollutants into harmless small molecules (CO₂ and H₂O). Meanwhile, ultraviolet light activates the photocatalyst (e.g., TiO₂) to generate strong oxidizing free radicals, further oxidizing residual pollutants for complete purification. This equipment is widely used for odor control in wastewater treatment plants, pumping stations, waste transfer stations, chemical plants, food processing facilities, and other locations.

• High-Efficiency Odor Removal

  Dual Purification Mechanism: Synergistic effect of high-energy UV photolysis + photocatalytic oxidation, removal efficiency up to 95%.

  Broad Spectrum Removal: Effectively removes hydrogen sulfide (H₂S), ammonia (NH₃), methyl mercaptan, VOCs, benzene series, and various odorous and organic pollutants.

  Complete Decomposition: Thoroughly decomposes pollutants into CO₂ and H₂O, no secondary pollution.

• High-Quality UV Lamps

  Imported/Domestic Quality Lamps: Quartz glass sleeves, high UV transmittance, service life up to 8,000-12,000 hours.

  Dual-Wavelength Output: 185nm + 254nm dual-band ultraviolet, enabling both direct photolysis and ozone-assisted oxidation.

  Modular Design: Lamps independently installed, easy replacement without affecting continuous system operation.

• Premium Materials

  Stainless Steel/PP Housing: Standard SS304 stainless steel, optional SS316L or PP material, corrosion-resistant, suitable for humid and corrosive environments.

  Mirror Polished Inner Wall: Enhances UV reflection efficiency, increasing light energy utilization.

  Protection Class: Control panel IP55 rated, suitable for outdoor installation.

1. light oxygen tube each tube is 150W service life up to 130000H.
2. Photooxygen catalytic plate with exceptional catalytic activity excellent water and UV resistance washable.
3. The pre-filter cotton is fire and dust proof and effectively separates and filters large debris.
4. This equipment does not need any mechanical action, no noise.
