Anti Corrosion Rubber Dredge Hose Custom Diameters Dredge Pipeline OEM
With years of experience in marine and dredging equipment manufacturing, Hongruntong Marine has established a reputation for producing high-quality, durable dredge hoses for global clients. Our dredge hoses are designed with a unique rubber compound formula, combining wear resistance and elasticity to withstand the harsh conditions of dredging operations, including continuous friction from abrasive particles and dynamic bending from equipment movement.
They are equipped with precision-machined flange connections that ensure tight sealing, preventing slurry leakage and environmental pollution, while complying with international standards such as GMPHOM 2009.
Our dredge hoses stand out for their long service life and low maintenance requirements, thanks to the high-quality raw materials and advanced manufacturing processes we adopt. We offer a full range of dredge hoses, including standard and customized models, to meet the diverse needs of port, river, and offshore dredging projects.
Hongruntong Marine's professional after-sales team provides 24/7 technical support and troubleshooting services, ensuring that our clients' projects proceed smoothly. We are committed to delivering cost-effective, high-performance products that exceed customer expectations.
| Material of Rubber | NR, NBR, SR, CR and etc |
| Material of Flange | Q235B carbon steel paint |
| Reinforcement Layer | Rubber, cord fabric and wire reinforcement |
| Size | 1/2" to 32" |
| Working Pressure | 5-22 Bar or As Request |
| Brand | Hongruntong Marine |
| Application | Water irrigation, mud dredging, water suction etc |
| Packing | Plastic Belt Packing |
| Working Temperature | -40 ℃ ~ +120 ℃ |
| Warranty | 36 Months |
| MOQ | 1 |
| Model | I.D. | W.P. | B.P. | Min Bending Radius | Wear Layer Thickness | Length |
|---|---|---|---|---|---|---|
| inch | mm | bar | bar | mm | mm | m | |
| HM-F150 | 6 | 150 | 5-10 | 15-30 | 8D | 10-20 | 11.8 |
| HM-F200 | 8 | 200 | 5-10 | 15-30 | 8D | 10-20 | 11.8 |
| HM-F250 | 10 | 250 | 5-10 | 15-30 | 8D | 10-20 | 11.8 |
| HM-F300 | 12 | 300 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-F350 | 14 | 350 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-F400 | 16 | 400 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-F450 | 18 | 450 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-F500 | 20 | 500 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-F600 | 24 | 600 | 15-20 | 45-60 | 15D | 20-30 | 11.8 |
| HM-F650 | 26 | 650 | 15-20 | 45-60 | 15D | 20-30 | 11.8 |
| HM-F700 | 28 | 700 | 20-25 | 60-75 | 15D | 30-50 | 11.8 |
| HM-F750 | 30 | 750 | 20-25 | 60-75 | 15D | 30-50 | 11.8 |
| HM-F800 | 32 | 800 | 20-25 | 60-75 | 15D | 30-50 | 11.8 |
| HM-F850 | 34 | 850 | 20-25 | 60-75 | 15D | 30-50 | 11.8 |
| HM-F900 | 36 | 900 | 25-30 | 75-90 | 15D | 30-50 | 11.8 |
| HM-F1000 | 40 | 1000 | 25-30 | 75-90 | 15D | 50-75 | 11.8 |
| HM-F1100 | 44 | 1100 | 25-30 | 75-90 | 15D | 50-75 | 11.8 |
- Compatible with All Dredging Equipment Types - Suitable for cutter suction dredgers, trailing suction hopper dredgers, and land-based dredge pumps.
- Internal Spiral Wire for Stability - Embedded spiral wire enhances suction capabilities and prevents hose collapse under vacuum pressure.
- Environmentally Safe Materials - Constructed with eco-friendly compounds that reduce risk of water pollution or chemical leaching.
- Field Tested in Harsh Marine Environments - Proven performance in large-scale projects around the world, from river deepening to offshore land reclamation.
- Harbor Maintenance Dredging - Supports routine dredging operations in harbors to maintain safe water depths and navigation channels.
- Pump Discharge Lines - Integrated as discharge lines from booster pumps in large-scale dredging projects, capable of handling high-pressure slurry transport.
- Lake and Lagoon Restoration - Deployed in ecological restoration projects for removing sediment buildup and improving water quality.
- Environmentally Friendly Materials - Our rubber formulation minimizes environmental impact and meets modern eco-safety guidelines.
- Excellent Flexibility and Pressure Resistance - Designed to perform under high working pressure with superior flexibility for easy handling.
- Trusted by Global Contractors and Dredgers - Long-term partners include reputable dredging companies, ports, and shipyards worldwide.
- Continuous Improvement and Innovation - Customer feedback drives ongoing upgrades to product performance, durability, and installation efficiency.
