4 Inch API 7K Rotary Drilling Hose 35-75 Mpa High Pressure for Drilling Rigs
Price:
$18-$130
MOQ:
1
Delivery Time:
5-7 Work Days
Brand:
Hongruntong Marine
Product Description
4 Inch API 7K Rotary Drilling Hose 35-75 Mpa High Pressure
Product Overview
4 Inch High Pressure Rotary Hose Flame Retardant Abrasion Proof Ultra Flexible
Rotary Drilling Hose Product Introduction
This API 7K certified rotary hose is engineered for high-performance deep well drilling operations. It handles high volumes of abrasive drilling mud under extreme pressure, maintaining integrity under constant flexing and vibration.
With a nitrile rubber inner tube and ozone-resistant synthetic rubber cover, it offers excellent oil resistance, making it ideal for onshore and offshore environments.
Case Study: A land-based drilling site in Texas encountered hose failures every 3-4 months due to mud contamination and cracking. They replaced their standard hoses with API 7K rotary drilling hoses equipped with dual spiral steel reinforcement. The new hoses remained in service for over 14 months, improving productivity and saving over $20,000 in replacement costs annually.
Specifications
| Tube | Modified nitrile, black, specifically engineered for the effective handling of abrasive, corrosive substances, and oil drilling mud. |
| Reinforcement | Composite construction featuring multiple layers of textile fabric and steel cable, with a layer of rubber positioned between the cable layers for enhanced performance. |
| Cover | Black modified nitrile with a specially engineered ultra-abrasion cover, designed to provide exceptional resistance to abrasion, corrosion, cutting, gouging, oil, and weather conditions. |
| Coupling | Swaged couplings, full range of couplings are available, such as hammer union, flanges, hubs, male thread etc. |
| Certification | API 7K-0376/ISO14693 |
| Temperature | -40°C to +82°C (-104°F to +180°F) |
| Options | Accessories such as safety clamps and hose lift eyes are available upon request. |
| Test | Each hose is tested at 22500psi for 15 minutes. Pressure test graph, test certificate and letter of conformance are issued for each hose. |
Product Models & Specifications
| Model | I.D. (inch) | I.D. (mm) | O.D. (mm) | W.P. mpa(psi) | T.P. mpa(psi) | Weight (kg/m) | B.R. (mm) |
|---|---|---|---|---|---|---|---|
| HMRDH-Grade A | 1 1/2 | 38 | 51 | 11(1500) | 22(3000) | 2.19 | 560 |
| HMRDH-Grade A | 2 | 51 | 65 | 11(1500) | 22(3000) | 3.03 | 900 |
| HMRDH-Grade A | 2 1/2 | 64 | 78 | 11(1500) | 22(3000) | 3.95 | 1200 |
| HMRDH-Grade B | 1 1/2 | 38 | 52 | 14(2000) | 28(4000) | 2.39 | 560 |
| HMRDH-Grade B | 2 | 51 | 66 | 14(2000) | 28(4000) | 3.25 | 900 |
| HMRDH-Grade B | 2 1/2 | 64 | 79 | 14(2000) | 28(4000) | 4.37 | 1200 |
| HMRDH-Grade B | 3 | 76 | 98 | 14(2000) | 28(4000) | 7.76 | 1200 |
| HMRDH-Grade B | 3 1/2 | 89 | 113 | 14(2000) | 28(4000) | 9.95 | 1300 |
| HMRDH-Grade B | 4 | 102 | 127 | 14(2000) | 28(4000) | 12.43 | 1400 |
| HMRDH-Grade B | 5 | 127 | 153 | 14(2000) | 28(4000) | 15.25 | 1500 |
| HMRDH-Grade B | 6 | 152 | 178 | 14(2000) | 28(4000) | 18.71 | 1600 |
| HMRDH-Grade C | 1 1/2 | 38 | 55 | 28(4000) | 56(8000) | 3.65 | 560 |
| HMRDH-Grade C | 2 | 51 | 69 | 28(4000) | 56(8000) | 5.15 | 900 |
| HMRDH-Grade C | 2 1/2 | 64 | 88 | 28(4000) | 56(8000) | 7.86 | 1200 |
| HMRDH-Grade C | 3 | 76 | 105 | 28(4000) | 56(8000) | 13.12 | 1200 |
| HMRDH-Grade C | 3 1/2 | 89 | 121 | 28(4000) | 56(8000) | 16.79 | 1300 |
| HMRDH-Grade C | 4 | 102 | 137 | 28(4000) | 56(8000) | 21.70 | 1400 |
| HMRDH-Grade C | 5 | 127 | 164 | 28(4000) | 56(8000) | 28.46 | 1500 |
| HMRDH-Grade C | 6 | 152 | 197 | 28(4000) | 56(8000) | 44.64 | 1600 |
| HMRDH-Grade D | 2 | 51 | 73 | 35(5000) | 70(10000) | 6.46 | 900 |
| HMRDH-Grade D | 2 1/2 | 64 | 91 | 35(5000) | 70(10000) | 10.75 | 1200 |
| HMRDH-Grade D | 3 | 76 | 107 | 35(5000) | 70(10000) | 14.35 | 1200 |
| HMRDH-Grade D | 3 1/2 | 89 | 123 | 35(5000) | 70(10000) | 18.77 | 1300 |
| HMRDH-Grade D | 4 | 102 | 139 | 35(5000) | 70(10000) | 23.16 | 1400 |
| HMRDH-Grade D | 5 | 127 | 171 | 35(5000) | 70(10000) | 38.00 | 1500 |
| HMRDH-Grade D | 6 | 152 | 200 | 35(5000) | 70(10000) | 48.43 | 1600 |
| HMRDH-Grade E | 2 | 51 | 80 | 52(7500) | 104(15000) | 10.37 | 1000 |
| HMRDH-Grade E | 2 1/2 | 64 | 101 | 52(7500) | 104(15000) | 17.88 | 1200 |
| HMRDH-Grade E | 3 | 76 | 120 | 52(7500) | 104(15000) | 24.45 | 1200 |
| HMRDH-Grade E | 3 1/2 | 89 | 135 | 52(7500) | 104(15000) | 29.33 | 1300 |
| HMRDH-Grade E | 4 | 102 | 148 | 52(7500) | 104(15000) | 34.24 | 1400 |
| HMRDH-Grade E | 5 | 127 | 189 | 52(7500) | 104(15000) | 55.39 | 1500 |
| HMRDH-Grade F | 2 | 51 | 82 | 70(10000) | 105(15000) | 11.81 | 1000 |
| HMRDH-Grade F | 2 1/2 | 64 | 104 | 70(10000) | 105(15000) | 20.46 | 1300 |
| HMRDH-Grade F | 3 | 76 | 129 | 70(10000) | 105(15000) | 32.74 | 1300 |
| HMRDH-Grade F | 3 1/2 | 89 | 144 | 70(10000) | 105(15000) | 39.43 | 1400 |
| HMRDH-Grade F | 4 | 102 | 158 | 70(10000) | 105(15000) | 45.73 | 1500 |
| HMRDH-Grade G | 2 | 51 | 92 | 105(15000) | 157(22500) | 17.37 | 1000 |
Key Features
High Vibration Tolerance
Designed to absorb shock and vibration from rotating equipment without compromising hose integrity.
Low Volumetric Expansion
Maintains consistent internal diameter under pressure for precise mud flow and pump calibration.
Leak Proof Connections
Equipped with high-quality hammer unions or flanged ends to ensure tight, secure fittings.
UV and Ozone Resistant
Outer cover is resistant to weathering, extending service life in outdoor rig environments.
Engineered for the Toughest Applications
- Water Well Drilling: Transports water-based mud and prevents collapse in aquifer drilling.
- Mining Mineral Exploration: Used in core drilling rigs for mineral sampling and blast hole drilling.
- Horizontal Directional Drilling (HDD): Flexible design accommodates tight bends in trenchless pipeline installations.
What Sets Us Apart
- Fast Response Technical Support: Our engineers provide quick guidance on product selection, troubleshooting, and installation best practices.
- OEM Private Label Available: We offer branding and packaging services for distributors and equipment manufacturers worldwide.
- Reliable Supply Chain for Raw Materials: Long-term partnerships with certified suppliers ensure stable quality and delivery timelines.
- Comprehensive After Sales Service: We provide installation guidance, maintenance instructions, and post-shipment support to minimize downtime.
Frequently Asked Questions
Q: Can the hoses handle high temperatures?
A: Yes, our hoses operate in temperatures ranging from -40°C to +120°C, with high-temp models up to +150°C.
Q: What is the minimum bending radius of your hose?
A: It varies by size and model, but our hoses are designed for excellent flexibility and anti-kinking.
Q: Are the hoses resistant to H₂S and acid-based fluids?
A: Yes, we offer H₂S-resistant and acid-proof inner tube options for sour gas drilling environments.
Q: What type of reinforcement is used?
A: We use multiple layers of high-tensile steel wire for strength, durability, and pressure resistance.
