Flexible Design Heavy Duty Dredge Pipeline for Reliable Performance in Slurry Conveying Systems
Price:
USD68 to USD970 Per Piece
MOQ:
1
Delivery Time:
5-7 Work Days
Brand:
Hongruntong Marine
Product Description
Dredging Hose Flexible Design Heavy Duty Reliable Performance
Dredge Pipeline is a flexible industrial slurry conveying system designed for mining, river dredging, and offshore engineering applications. It is manufactured using high-strength rubber composite materials combined with reinforced steel wire or textile layers to ensure stable performance under abrasive and high-pressure working conditions.
The pipeline is designed for continuous transport of sand, mud, tailings, and other abrasive materials. It offers excellent wear resistance, corrosion resistance, and structural flexibility, making it suitable for complex environments such as uneven terrain, floating dredging systems, and long-distance slurry transfer. Compared with traditional steel pipelines, it provides easier installation, lower maintenance cost, and higher operational efficiency.
Case Study - South America Mining Tailings Project
A copper mining company in Chile required a reliable slurry transport system for moving tailings across a 4 km uneven terrain area. The previous steel pipeline system frequently suffered from misalignment, cracking, and downtime due to ground movement and heavy abrasion.
Hongruntong Marine supplied a modular dredge pipeline system with reinforced flexible structure and wear-resistant inner lining. After installation, the system operated continuously with stable performance.
The project achieved a 50% reduction in maintenance downtime and significantly improved transport efficiency. The client confirmed that the system performed well under long-distance high-density slurry conditions and greatly improved operational continuity.
Specifications
| Material of Rubber | NR, NBR, SR, CR and etc |
| Material of Flange | Q235B carbon steel paint |
| Reinforcement Layer | Rubber, cord fabric and wire reinforcement |
| Size | 1/2" to 32" |
| Working Pressure | 5-22 Bar or As Request |
| Model Number | HMDH |
| Brand | Hongruntong Marine |
| Application | Water irrigation, mud dredging, water suction etc |
| Packing | Plastic Belt Packing |
| Working Temperature | -40 ℃ ~ +120 ℃ |
| Warranty | 36 Months |
| MOQ | 1 |
Technical Specifications
| Model | I.D. | W.P. | B.P. | Min Bending Radius | Wear Layer Thickness | Length |
|---|---|---|---|---|---|---|
| inch | mm | bar | bar | mm | mm | mm | |
| HM-DP150 | 6 | 150 | 5-10 | 15-30 | 8D | 10-20 | 11.8 |
| HM-DP200 | 8 | 200 | 5-10 | 15-30 | 8D | 10-20 | 11.8 |
| HM-DP250 | 10 | 250 | 5-10 | 15-30 | 8D | 10-20 | 11.8 |
| HM-DP300 | 12 | 300 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-DP350 | 14 | 350 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-DP400 | 16 | 400 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-DP450 | 18 | 450 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-DP500 | 20 | 500 | 10-20 | 30-60 | 12D | 12-25 | 11.8 |
| HM-DP600 | 24 | 600 | 15-20 | 45-60 | 15D | 20-30 | 11.8 |
| HM-DP650 | 26 | 650 | 15-20 | 45-60 | 15D | 20-30 | 11.8 |
| HM-DP700 | 28 | 700 | 20-25 | 60-75 | 15D | 30-50 | 11.8 |
| HM-DP750 | 30 | 750 | 20-25 | 60-75 | 15D | 30-50 | 11.8 |
| HM-DP800 | 32 | 800 | 20-25 | 60-75 | 15D | 30-50 | 11.8 |
| HM-DP850 | 34 | 850 | 20-25 | 60-75 | 15D | 30-50 | 11.8 |
| HM-DP900 | 36 | 900 | 25-30 | 75-90 | 15D | 30-50 | 11.8 |
| HM-DP1000 | 40 | 1000 | 25-30 | 75-90 | 15D | 50-75 | 11.8 |
| HM-DP1100 | 44 | 1100 | 25-30 | 75-90 | 15D | 50-75 | 11.8 |
Features
Flexible Structural Design for Complex Terrain
The pipeline is designed with reinforced flexible layers that allow it to adapt to uneven terrain, floating dredging systems, and dynamic industrial environments. This ensures stable slurry transport even under movement and vibration conditions without structural damage.
The pipeline is designed with reinforced flexible layers that allow it to adapt to uneven terrain, floating dredging systems, and dynamic industrial environments. This ensures stable slurry transport even under movement and vibration conditions without structural damage.
High Wear Resistant Flow Channel
The inner layer is engineered with abrasion-resistant rubber material that minimizes erosion caused by sand, gravel, and mineral particles. This improves service life and maintains consistent flow efficiency in high-intensity dredging operations.
The inner layer is engineered with abrasion-resistant rubber material that minimizes erosion caused by sand, gravel, and mineral particles. This improves service life and maintains consistent flow efficiency in high-intensity dredging operations.
High Pressure Stability System
Multiple reinforcement layers provide strong resistance against internal pressure fluctuations. The pipeline maintains structural integrity during long-distance slurry transport under heavy load conditions.
Multiple reinforcement layers provide strong resistance against internal pressure fluctuations. The pipeline maintains structural integrity during long-distance slurry transport under heavy load conditions.
Modular Quick Connection Design
The pipeline uses a modular coupling system that allows fast installation, replacement, and extension. This reduces downtime and improves flexibility during field operations.
The pipeline uses a modular coupling system that allows fast installation, replacement, and extension. This reduces downtime and improves flexibility during field operations.
Applications
- Mining Slurry Transport Systems - Used for long-distance transport of mineral tailings and slurry in mining operations.
- River Dredging Projects - Applied in sediment removal and waterway maintenance engineering.
- Industrial Waste Transport Systems - Suitable for slurry and industrial byproduct handling applications.
Why Choose Hongruntong Marine
- Engineering-Based Product Development - Our pipeline systems are designed based on real mining and dredging operational conditions, ensuring reliable performance in complex environments.
- High Quality Material Selection - We use premium rubber compounds and reinforced composite structures to ensure durability and long service life.
- Customized Manufacturing Capability - We provide tailored pipeline diameter, pressure rating, and structural reinforcement according to project requirements.
- Global Project Experience - Our products are widely used in international mining and dredging projects with stable performance and reliable delivery.
FAQ
1. What is dredge pipeline used for?
It is used for transporting slurry, sand, mud, and tailings in mining, dredging, and industrial projects.
2. Can dredge pipeline be used in mining operations?
Yes, it is widely used for mining slurry and tailings transportation systems.
3. Is the pipeline suitable for uneven terrain?
Yes, its flexible structure allows adaptation to ground movement and complex terrain.
4. Can the pipeline be customized?
Yes, we can customize diameter, length, and pressure rating according to project requirements.
5. How is the pipeline installed?
It uses a modular connection system for fast and easy installation in field conditions.
