Quartz Sand Filter Wastewater Treatment Tank For Swimming Pool Suspended Solids And Sediment
Quartz sand filter, wastewater treatment filter tank, swimming pool water treatment, removal of suspended solids and sediment
Non-standard equipment
Mechanical filter tank
Classification of filling media:Quartz sand filter,Activated carbon filter
Introduction
Mechanical filters are suitable for industrial or domestic water treatment equipment in enterprises and urban areas that require filtered water with a turbidity generally within 5mg/L and meet drinking water quality standards.
Suspended solids, condensed flakes, sediment, iron, manganese, and adhesive colloidal particles that cannot be removed by precipitation methods in water can be filtered through the filter layer installed inside the filter to make the water transparent. It also has a good removal effect on suspended solids and solid substances in industrial wastewater.
Parameter
| model | Water treatment capacity (m³/d) | outline dimension(mm) | total height(mm) | inlet pipe | outlet pipe | Backwash tube |
| SZ-4 | 4 | φ800×1500 | 2450 | DN50 | DN50 | DN50 |
| SZ-6 | 5 | Φ900×1500 | 2500 | DN50 | DN50 | DN50 |
| SZ-8 | 8 | φ1000×1500 | 2550 | DN65 | DN65 | DN65 |
| SZ-10 | 10 | Φ1200×1800 | 2850 | DN65 | DN65 | DN65 |
| SZ-15 | 15 | Φ1500×1800 | 3100 | DN65 | DN65 | DN65 |
| SZ-20 | 20 | Φ1800×1800 | 3280 | DN80 | DN80 | DN80 |
| SZ-25 | 25 | φ2000×2000 | 3580 | DN80 | DN80 | DN80 |
| SZ-30 | 30 | Φ2200×2000 | 3680 | DN80 | DN80 | DN80 |
| SZ-35 | 35 | φ2400×2000 | 3780 | DN80 | DN80 | DN80 |
| SZ-40 | 40 | Φ2500×2200 | 4050 | DN80 | DN80 | DN80 |
| SZ-45 | 45 | φ2600×2200 | 4100 | DN80 | DN80 | DN80 |
| SZ-50 | 50 | φ2800×2200 | 4200 | DN100 | DN100 | DN100 |
| SZ-55 | 55 | φ3000×2000 | 4100 | DN100 | DN100 | DN100 |
