CE Industrial Stainless Steel Soap Noodles Mixing Machine Sigma Double Z Arm Mixer
-
Industrial-grade “Sigma”-type agitator paddles: achieve uniform mixing of materials.
-
Differential-speed contra-rotating paddles: promote full integration of ingredients.
-
Quick-clean blade geometry: simplifies servicing and reduces cleaning downtime.
-
Air-operated discharge gate: permits smooth, unobstructed product emptying.
-
Premium gearbox and drive motor: deliver dependable, stable performance.
-
Stainless-steel product-contact components: resist corrosion and comply with sanitary requirements.
| Model | M-180 |
|---|---|
| Capacity | 100 kg per batch |
| Power | 5.5 kW |
| Speed | 32 r/min |
| Dimensions | 2240 × 810 × 1400 mm |
| Weight | 670 kg |
| Motor Brand | LOVO (Chinese made) |
| Material Options | Carbon steel (standard) / Stainless steel 304 (for toilet soap production) |
The Sigma-blade mixer is designed for manufacturing a broad range of soap products, such as laundry soap, transparent soap, and specialty grades. It provides effective blending of base materials, fine soap pellets, and even incorporation of additives, auxiliaries, and fragrance.
The standard workflow is as follows:
-
Load 100 kg of soap pellets into the mixer.
-
Start the machine.
-
Introduce the remaining additives in sequence, with fragrance added last.
-
Blend for 5–10 minutes until a homogeneous mixture is achieved.
-
Slowly open the discharge gate and let the material fall onto the conveyor belt.
-
Adjust the discharge rate to suit grinding and conveying requirements.
This process ensures complete and consistent combination of soap pellets and additives. Color paste and other ingredients dissolve fully within the soap mass, thereby guaranteeing stable product quality.
