6V 12mm N20 Micro Brushed DC Metal Gear Motor with Stainless Steel Gears for Precision Machinery
N20 brushed DC metal gear motors with stainless steel gears available in a wide range of gear ratios for electronic lock applications and precision machinery.
- Middle Power version with 0.7A stall current
- 12CPR without encoder option
- Available with or without back shaft
- Choice of metal brush or carbon brush
| Model | Voltage (VDC) | No Load Speed (rpm) | No Load Current (mA) | Stall Torque (kg.cm) | Gear Ratio |
|---|---|---|---|---|---|
| N20M5 | 6V/12V | 4400 rpm | 40/20mA | 0.1 kg.cm | 5:1 |
| N20M10 | 6V/12V | 2200 rpm | 40/20mA | 0.2 kg.cm | 10:1 |
| N20M20 | 6V/12V | 1100 rpm | 40/20mA | 0.4 kg.cm | 20:1 |
| N20M30 | 6V/12V | 730 rpm | 40/20mA | 0.5 kg.cm | 30:1 |
| N20M50 | 6V/12V | 420 rpm | 40/20mA | 0.8 kg.cm | 50:1 |
| N20M75 | 6V/12V | 290 rpm | 40/20mA | 1.2 kg.cm | 75:1 |
| N20M100 | 6V/12V | 220 rpm | 40/20mA | 1.5 kg.cm | 100:1 |
| N20M150 | 6V/12V | 150 rpm | 40/20mA | 1.7 kg.cm | 150:1 |
| N20M210 | 6V/12V | 100 rpm | 40/20mA | 2.4 kg.cm | 210:1 |
| N20M250 | 6V/12V | 90 rpm | 40/20mA | 2.8 kg.cm | 250:1 |
| N20M298 | 6V/12V | 75 rpm | 40/20mA | 3.3 kg.cm | 298:1 |
| N20M380 | 6V/12V | 58 rpm | 40/20mA | 4.2 kg.cm | 380:1 |
| N20M1000 | 6V/12V | 22 rpm | 40/20mA | 6.0 kg.cm | 1000:1 |
This type of gearbox motor is mainly used in electronic locks, robots, cameras and small machinery.
- Intelligent door locks, electronic lock bodies
- Intelligent curtains, electric curtain tracks
- Smart toilet, automatic bathroom lid closing
- Shared charging stations, automatic devices
- Electric toothbrushes, beauty devices
- Camera pan-tilt, auto-focus mechanisms
- Robots, small mechanical arms
- Automotive electronics: mirrors, seat adjustment
- Smart Home: window openers, pet feeders
- Security equipment: surveillance cameras
- Financial equipment: printers, card dispensers
- Electronic toys, remote-controlled vehicles
- Medical equipment: pumps, analyzers
- Office equipment: printers, scanners
- UAV gimbal, model aircraft mechanisms
- ODM & OEM services
- Gearbox design and development
- Related technology support
Packed in nylon first, then carton, and reinforced with wooden case for outer packing. Custom packaging available according to client requirements.
Samples shipped within 10 days. Batch order lead time varies according to actual situation.
SHENZHEN XINHE MOTOR Co., Ltd, located in Shenzhen city, is a specialized factory producing AC/DC motors for various applications including kitchen appliances, air flow products, air conditioners, water heaters, pumps, power tools, robots, 3D printers, medical products, smart wear, electrical toys, and household appliances.
With over 16 years of experience working with major brands, we understand what matters to you and your consumers across various industries. Our management philosophy emphasizes humanistic values and supreme credibility, while our quality consciousness drives us to strive for perfection.
We offer comprehensive motion solutions including powerful DC brushed and brushless motors, supported by experienced engineers and extensive application expertise. Our products are successfully sold in more than 20 countries worldwide.
We provide complete professional solutions including superior customer service, reliable high-quality products, innovative design, wide product range, competitive prices, and convenient ordering quantities. We are fully compliant with EU & America restrictions and regulations including CE standards, RoHS, child safety, environmental safety, and social responsibility.
Our company comprehensively promotes ISO9001:2001 management systems and supplies motors to many famous worldwide companies with top brands across Europe, America, Middle East, East Asia, and South America markets.
