100 Bar 30 Slot Anti Aging Johnson Type Wire Screen Pipe Used In Oil Well

100 Bar 30 Slot Anti Aging Johnson Type Wire Screen Pipe Used In Oil Well

ISO9000 Approved Johnson Wire Screen Low Carbon Steel Galvanized Material

Johnson Wire Screen Description:

Johnson Wire Screen Regular Specifications:

Material: stainless steel 302, 304, 316, 304L, 316L or low carbon galvanized

O.D.: 3, 4, 6, 8, 10, 12 inch and as request.

Slot: 0.1mm - 35mm

Discrepancy: + / - 0.05mm

Length: 300mm-6000mm

End Connection: welded rings or thread couplings ( male / female )

Specification of the wrap wire:1*2mm, 2*3mm, 2.2*3.5mm, 3*4.6mm and so on.

Specification of the rod:2.8mm, 3.0mm, 3.8mm, 4.0mm, 4.2mm, 4.5mm, 5.0mm and so on.

Special specification can be made according to your need.

Johnson Wire Screen Characteristic:

Well Screen.Johnson screen is manufactured with V-shaped profile wire which is spirally wound around a cage of longitudinal support rods. Each intersecting point of these wires is fusion welded. The pitch of winding gives different spacing between two adjacent turns of wire. This spacing gives passage for water to enter. The entire process is completed on fully computerized machines.

Johnson Wire Screen Advantages:

Not easy to jam

the special V shaped wire, make the hole of screen outside face is smaller than inside, so the hole is not easy to jam.

Slot even

The CNC machine tools strictly control the gap between the wire, so that the gap is even.

Strong corrosion resistance

Stainless steel 304 have the high corrosion resistance

Johnson Wire Screen Industry:

Johnson Screens specific continuous-slot construction aims to optimize flow rates, minimize clogging and help develop the water-bearing geological formations faster. It is best applied in the following situations:

Geological formations comprised of small, fine particles

Water wells where gravel packs will be installed

Thin aquifers, where maximum open area is required

Large- and small-diameter deep wells
