273mm Non Magnetic Stainless Steel Vee Shaped Continuous Slot Water Wire Screen
273mm Non Magnetic Stainless steel Vee Shaped Continuous Slot Water Wire Screen
Continuous Slot Johnson type Water Wire Screen Use:
High Strength Continuous Slot Stainless Steel Water Wire Screen has been known as the world's leading manufacturer and provider of industrial filters since 1904.We provide screening solutions to almost every industry,including:
Water well
Water supply systems
Refining & petrochemical
Filter equipment
Drum Filter
Sand control
Continuous Slot Johnson Water Wire Screen Groundwater Product Description:
1: Continuous Slot Johnson Water Wire Screen Used For Drum FIlter is manufactured with V-shaped profile wire which is spirally wound around a cage of longitudinal support rods.
2: Each intersecting point of these wires is fusion welded. The pitch of winding gives different spacing between two adjacent turns of wire. This spacing gives passage for water to enter. The entire process is completed on fully computerized machines.
Continuous Slot Johnson type Water Wire Screen Specificarion:
| Material | Non Magnetic Stainless steel |
| Diameter | 10-3/4" , 8-5/8" |
| O.D | 273mm, 219mm |
| Slot Size | 0.25mm |
| Length | 5850mm |
| End connection | Welded rings |
| Wire shaped | Vee shaped |
| Wire size | 2.2*4.5mm vee shaped wire, 2.2mm is the width and 4.5mm is the height |
| Support rod | ø5.0mm |
| Support rod shaped | Round wire |
Continuous Slot Johnson Water Wire Screen Characteristic:
High Strength Continuous Slot Stainless Steel Water Wire Screen have superior open area due to their continuous slot openings.
The benefits of which will :
• Reduce energy consumption and increase water flow.
• Reduce erosion of entry surfaces and increase well life.
• Allow a uniform and efficient well development.
• Reduce significantly potential pump damage and subsequent maintenance costs.
Continuous Slot Johnson Water Wire Screen Regular Specification:
| SIZE (INCH) | O.D (MM) | SLOT (MM) | LENGTH (M) | COLLAPSE STRENGTH (BAR) | TENSILE WEIGHT (TON) | WRAP WIRE(WIDTH*HEIGHT) (MM) | RODS (MM) |
| 3-1/2 | 88.9 | 1.0 | 3 | ＞22 | 10.2 | 2.3*3.5 | 3.8MM/22 |
| 4-1/2 | 114.3 | 1.0 | 3 | ＞28 | 11.5 | 2.3*3.5 | 3.8MM/22 |
| 6-5/8 | 168.3 | 0.75 | 5.8 | ＞40 | 12.8 | 2.3*3.5 | 3.8MM/32 |
| 6-5/8 | 168.3 | 1.0 | 5.8 | ＞33 | 12.8 | 2.3*3.5 | 3.8MM/32 |
| 6-5/8 | 168.3 | 0.63 | 5.8 | ＞83 | 45 | 3.2*6.0 | 6.0MM*32 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞34 | 21.9 | 2.3*3.5 | 3.8MM/48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞50 | 38.2 | 3.0*5.0 | 4.0MM/48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞60 | 46 | 3.2*6.0 | 5.0MM/48 |
| 10-3/4 | 273.1 | 0.75 | 5.8 | ＞50 | 32.9 | 2.3*3.5 | 4.9MM/55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | ＞60 | 39.5 | 3.0*5.0 | 4.9MM/55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | ＞100 | 48 | 3.2*6.0 | 5.0MM/55 |
| 12-3/4 | 323.9 | 1.0 | 5.8 | ＞120 | 37.2 | 3.0*5.0 | 4.0MM/50 |
| 14 | 355.6 | 1.0 | 3 | ＞80 | 37.8 | 3.0*5.0 | 4.0MM/59 |
Continuous Slot Johnson Water Wire Screen OEM service:
Please tell us the specification of the wire screen you need, we will help you to process the high quality product.
