Custom TN HTN STN FSTN VA LCD Display for Water Meter with Wide Operating Temperature and Customizable View Direction
Price:
$0.50-1 / piece
MOQ:
10 pieces
Delivery Time:
Negotiable
Brand:
BAIYOU
Product Description
Baiyou Technology
manufacturer custom tn htn stn fstn va lcd for water meter
| NO. | ITEM | SPECIFICATIONS |
|---|---|---|
| 1 | Product Name | Customized TN LCD for water meter |
| 2 | Operating Voltage | 2.8V |
| 3 | Operating Temperature | -10~+60℃ |
| 4 | Connector | PIN |
| 5 | View Direction | 3/6/9/12 O'clock |
| 6 | Backlight | No |
| 7 | Display Color | Gray |
| 8 | Polarizer Type | Reflective |
| 9 | Driver IC | Optional |
| 10 | RoHS Compliant | Yes |
| Item | Contents |
|---|---|
| Construction: | lcd,cog,lcd+bl,lcd+bl+cob,according to your requiremts |
| LCD type: | VA(NBT/EBN/IBN),TN, HTN, STN, FSTN, FFSTN/DFSTN |
| Polarizer: | Transflective, Transmissive, Reflective, Anti-Glare, Anti-UV |
| Background: | Gray, Yellow-Green, Blue, Black,white |
| Viewing direction: | 6:00, 12:00, 3:00, 9:00, Customization |
| Operating temperature: | 0 ℃ to 50 ℃, -20 ℃ to +70 ℃, -30 ℃ to +80 ℃, -30 ℃ to +85 ℃, Customization |
| Storage temperature: | -10 ℃ to +60 ℃, -20 ℃ to +70 ℃, -30 ℃ to +80 ℃, -40 ℃ to +90 ℃, Customization |
| Drive Method | Static or dynamic |
| Votage(VOP): | according to your requirement |
| Connection: | Metal PIN, Rubber/Zebra, Heat seal, Flat cable(FPC) |
