BHE204L Model Two-Stage Compression High-Precision Machining Air End for Industrial Compressors
Baosi BHE204L is a heavy-duty two-stage oil-injected screw airend, engineered for high-power industrial air compressors. Featuring upgraded rotor profile and optimized two-stage compression design, it delivers large air displacement and outstanding overall efficiency.
With multiple gear ratio options, it adapts to wide exhaust pressure ranges for diverse industrial working conditions. Adopting low-speed direct drive structure and refined oil circuit layout, it realizes lower noise, lower vibration and remarkable energy-saving performance.
Equipped with high-precision machining rotors, anti-corrosion surface coating and reinforced sealing system, it effectively reduces internal leakage and oil leakage. Rugged and durable, it supports 24-hour continuous heavy-load operation. Compact and reasonably structured, it is easy to install and maintain, serving as an ideal core component for large industrial compressed air systems.
| Model / Gear Ratio | Technical Parameters | 0.6 MPa | 0.8 MPa | 1.0 MPa | 1.3 MPa | 1.5 MPa | 1.7 MPa |
|---|---|---|---|---|---|---|---|
| BHE204L / 1.29 | Shaft Power (kW) | 76.7 | 84.3 | 94.8 | 107.6 | 118.1 | 130.9 |
| Capacity/F.A.D (m³/min) | 15.32 | 15.24 | 15.16 | 15.08 | 14.92 | 14.76 | |
| Oil Heat Dissipation (kW) | 61.4 | 67.5 | 75.8 | 86.1 | 94.5 | 104.7 | |
| Oil Flow Rate (L/min) | 96.4 | 108.7 | 125.5 | 146.1 | 163.0 | 183.8 | |
| BHE204L / 1.61 | Shaft Power (kW) | 95.5 | 105.0 | 118.0 | 134.0 | 147.0 | 163.0 |
| Capacity/F.A.D (m³/min) | 19.00 | 18.90 | 18.80 | 18.70 | 18.50 | 18.30 | |
| Oil Heat Dissipation (kW) | 76.4 | 84.0 | 94.4 | 107.2 | 117.6 | 130.4 | |
| Oil Flow Rate (L/min) | 120.2 | 135.5 | 156.4 | 182.0 | 203.1 | 228.9 | |
| BHE204L / 1.89 | Shaft Power (kW) | 110.7 | 121.7 | 136.8 | 155.4 | 170.4 | 189.0 |
| Capacity/F.A.D (m³/min) | 22.38 | 22.27 | 22.15 | 22.03 | 21.79 | 21.56 | |
| Oil Heat Dissipation (kW) | 88.6 | 97.4 | 109.4 | 124.3 | 136.3 | 151.2 | |
| Oil Flow Rate (L/min) | 138.7 | 156.5 | 180.7 | 210.5 | 234.9 | 264.9 | |
| BHE204L / 2.02 | Shaft Power (kW) | 118.4 | 130.2 | 146.3 | 166.2 | 182.3 | 202.1 |
| Capacity/F.A.D (m³/min) | 23.94 | 23.81 | 23.69 | 23.56 | 23.31 | 23.06 | |
| Oil Heat Dissipation (kW) | 94.7 | 104.2 | 117.1 | 132.9 | 145.8 | 161.7 | |
| Oil Flow Rate (L/min) | 148.4 | 167.3 | 193.3 | 225.1 | 251.2 | 283.3 | |
| BHE204L / 2.24 | Shaft Power (kW) | 131.3 | 144.4 | 162.3 | 184.3 | 202.1 | 224.2 |
| Capacity/F.A.D (m³/min) | 26.53 | 26.39 | 26.25 | 26.11 | 25.83 | 25.55 | |
| Oil Heat Dissipation (kW) | 105.1 | 115.5 | 129.8 | 147.4 | 161.7 | 179.3 | |
| Oil Flow Rate (L/min) | 164.6 | 185.6 | 214.4 | 249.7 | 278.6 | 314.2 |
- Heavy-Duty Configuration: High-performance two-stage oil-injected screw airend customized for high-power industrial air compressor units, with strong load-bearing capacity to meet large-scale industrial gas supply demands.
- High Efficiency & Energy Saving: Optimized rotor profile and low-speed operation design greatly improve compression efficiency and achieve outstanding energy-saving performance.
- Strong Working Condition Adaptability: Multiple gear ratio options available, suitable for wide exhaust pressure ranges and working conditions with high air demand.
- Durable & Reliable: High-precision machined rotors with anti-corrosion coating; reinforced sealing structure effectively reduces internal leakage and oil leakage.
- Strict quality inspection, meeting international standards
- Providing customized OEM and ODM solutions
- Stable mass production, on-time delivery
- Providing comprehensive pre-sales, sales, and after-sales services
Shenzhen Bebaios Machinery Co., Ltd. boasts over 10 years of professional expertise in manufacturing and exporting air compressors. We offer comprehensive one-stop solutions, covering product design, system installation, equipment maintenance, after-sales support and technical consulting, fully meeting the diverse needs of global customers.
With a customer-centric approach, we have established long-term, stable cooperative partnerships with clients across the world. Guided by our core values of Focus, Reliability, Innovation and Professionalism, we remain committed to delivering premium-quality products and reliable services to both new and existing customers, striving to become a trusted partner in the air compressor industry.
