China Heavy-Duty Shacman 4X2 Truck for Sludge and Coal Ash Transport for sale

Heavy-Duty Shacman 4X2 Truck for Sludge and Coal Ash Transport

Price Negotiable

Price: US $48,888 / Piece

MOQ: 1

Delivery Time: 15 working days

Product Description

Shaanxi steam brand SX3180GPN461-type dump truck

[Vehicle technical parameters]
Product trademark	Shaanxi automobile brand	Announcement batch	384
product name	dumper	product model	SX3180GPN461
gross mass (Kg)	18000	Tank volume (m3)
Rated load mass (Kg)	8970,8905	outline dimension (mm)	7965×2550,2500×3200,2820,3150,2880
curb weight (Kg)	8900	Goods Chamber Size (mm)	5200×2350,2300×800
Number of passengers (person)	2,3	Maximum saddle load mass (Kg)
Approach angle / departure angle of (°)	18/18	Front suspension / rear suspension (mm)	1450/1915
axle weight (Kg)	6500/11500	Top vehicle speed (Km/h)	85
[Chassis technical parameters]
Chassis model	SX3180GPN461	Chassis name	Self-unloading car chassis
brand name	Shaanxi automobile brand	manufacturing enterprise	Shaanxi Automobile Group Co., Ltd
number of axles	2	Number of tires	6
wheel base (mm)	4600
tyre size	10.00R20,11.00R20,11R22.5,10.00R20 18PR,11.00R20 18PR,11R22.5 18PR
Number of steel plate spring sheets	9/10+8,9/11+8	front gauge (mm)	1970
Fuel types	LNG	rear track (mm)	1860
Emission basis standard	The GB17691-2018 countries
engine type	Engine production enterprise	displacement (ml)	power (Kw)
YCA07260N-60	Guangxi Yuchai Machinery Co., LTD	6871	191

Car configuration: The car is made of high-strength steel plates, electrophoretic technology, with 110 oil cylinders on the middle and double tops. The thickness of the box body is 3mm for the side plates and 4mm for the bottom plate
