China Manufacturer 450W PV and 1200W Thermal 540W PV and 1500W Thermal All in One Hybrid Pvt Solar Panel
Price:
420
MOQ:
28
Delivery Time:
Negotiable
Product Description
PVT Solar Panel (Photo-voltaic&Thermal collector)
![]()
Number of cells: 60(6*10)
Cell Type: polycrystalline 156*156mm
Dimension: 1640*992*40mm
Net weight: 25KG
Front glass: 3.2mm tempered low iron
Frame: Anodized aluminum
Junction box: IP67, with bypass diodes
Connector: MC4 compatible
Output cables: TUV, 900mm length, 4.0mm2
Simulation of System:
10KW PVT solar collectors project
can offer 5000 liter hot water at 60°C per day.
Features of PVT Solar Collector
1, Improve Photo-voltaic efficiency 15%
2, Save installation cost and area
3, Combine the photovoltaic and heating all in one
![]()
![]()
![]()
![]()
Number of cells: 60(6*10)
Cell Type: polycrystalline 156*156mm
Dimension: 1640*992*40mm
Net weight: 25KG
Front glass: 3.2mm tempered low iron
Frame: Anodized aluminum
Junction box: IP67, with bypass diodes
Connector: MC4 compatible
Output cables: TUV, 900mm length, 4.0mm2
| ELECTRICAL CHARACTERISTICS (STC) | ||||
| Peak Power Watts-* | PMAX | (Wp) | 270 | |
| Power Output Tolerance | PMAX | (W) | 0 ~ +3% | |
| Maximum Power Voltage | VMPP | (V) | 30.98 | |
| Maximum Power Current | IMPP | (A) | 8.91 | |
| Open Circuit Voltage | VOC | (V) | 43.3 | |
| Short Circuit Current | ISC | (A) | 9.71 | |
| Module Efficiency | ? | (%) | 18.40 | |
| STC: Irradiance 1000W/m², Cell Temperature 25°C, Air Mass AM1.5. | ||||
| Thermal collector specification | ||||
| Peak Power Watts | 760W | |||
| Collector Efficiency | 46% | |||
| insulation layer | Glass wool | |||
| flowing tube | Aluminium-copper Φ8x0.6 mm | |||
| Number of flowing tube | 6pcs | |||
| Header tube | copper Φ16x0.8 mm | |||
| Back sheet | Galvanized steel , thickness:0.4mm | |||
| Working Pressure | 0.6Mpa | |||
| Working temperature | Minus 35 degree celsius to 150 degree celsius | |||
Simulation of System:
10KW PVT solar collectors project
can offer 5000 liter hot water at 60°C per day.
Features of PVT Solar Collector
1, Improve Photo-voltaic efficiency 15%
2, Save installation cost and area
3, Combine the photovoltaic and heating all in one
