SS316 / 316 Flexible Stainless Steel Cable Mesh Ferruled Provide Cutting Welding And Bending Services
SS316 / 316 Stainless Steel flexible wire mesh Ferruled Provide cutting, welding and bending services
SS316 ferrule type stainless steel wire rope mesh – also known as ferrule cable mesh, ferrule wire rope netting, or SS316 ferrule rope mesh – is a high-strength, corrosion-resistant mesh system made from stainless steel wire ropes joined together by stainless steel ferrules at each intersection. The ferrule type mesh is of the same physical properties as knotted mesh; the only difference is in the combination style, where the wire ropes are combined by ferrules which are made of the same grade stainless steel to form consistent diamond-shaped openings with a standard 60° angle, though other angles such as 20°, 30°, 70° and 75° are also available.
Key Features
| Feature | Benefit |
|---|---|
| High tensile strength | Multi‑wire stranded rope construction delivers high breaking strength for heavy‑duty safety and load‑bearing applications |
| Superior corrosion resistance | SS316 stainless steel resists rust, saltwater, chlorides and harsh chemicals – suitable for marine, coastal and outdoor environments |
| Excellent flexibility | Ferrule connections allow the mesh to bend and conform to curved surfaces while maintaining full structural integrity |
| High transparency & aesthetics | Open diamond weave provides unobstructed viewing, light transmission and air flow – ideal for architectural and zoo applications |
| UV and weather resistant | Performs reliably under prolonged sunlight exposure, rain, snow and extreme temperatures |
| Light weight relative to strength | Easy to transport, handle and install compared to rigid metal panels |
| Long service life | Expected lifespan of more than 30 years in standard outdoor conditions |
| Custom fabrication available | Cutting, welding and bending services available to meet project‑specific dimensional and configuration requirements |
| 100% recyclable | Environmentally friendly – fully recyclable at end of service life |
| Parameter | Specification / Range |
|---|---|
| Material grade | SS316 / 316 stainless steel (AISI 316) |
| Rope Diameter | 1.0 mm – 6.0 mm (customizable) |
| Wire rope construction | 7×7 or 7×19 |
| Weaving method | Ferrule type |
| Mesh opening | 20x35mm to 70x121mm Custom Mesh Opening: ≥20mm |
| Opening angle | 60° (standard); other angles: 20°, 30°, 70°, 75° on request |
| Panel dimensions | Customizable to project requirements |
| Surface finish | PVDF Coating |
| Certification | ISO 9001‑2015 |
1.Architectural & Decorative Applications:
Building facades, curtain walls, balustrade infill, staircase partitions, green wall systems, interior partitions, atrium safety nets, and sunshade screens – providing modern transparent aesthetics, structural integrity, unobstructed views, fall protection, and solar shading.
2.Zoo & Animal Enclosures:
Animal enclosures for mammals, birds, primates, large cats; bird aviaries; shark tunnels; marine parks; wildlife park barriers – escape‑proof ferrule locking, high transparency for viewing, corrosion resistance for saltwater, and durable animal impact resistance.
3.Safety & Fall Protection:
Construction site safety nets (EN1263‑1 certified), debris containment netting, edge protection systems, bridge side‑protection nets – installed around scaffolding, elevator shafts, roof perimeters, and bridge edges to catch falling persons or debris.
4.Marine & Offshore Applications:
Oil rig and ship deck perimeter nets, dock and marina barriers, offshore platform guard nets, coastal building protection – SS316 construction withstands continuous saltwater exposure, tidal zones, and harsh marine conditions with minimal maintenance.
5.Geotechnical & Slope Protection:
Rockfall prevention netting draped over unstable slopes, landslide debris barriers with multiple layers, mine shaft and quarry safety barriers – containing falling stones, boulders, and debris around open pits, conveyors, and blast areas.
6.Security & Perimeter Protection:
Perimeter security fencing for critical infrastructure, anti‑climb fencing for commercial sites, stadium and event barrier mesh – high strength, tamper‑resistant ferrule construction, prevents climbing while maintaining visibility and airflow for crowd control.
7.Industrial Safety:
Machine guarding around moving machinery and robotic cells, warehouse mezzanine barriers along elevated walkways, crane and hoist safety zones – tensioned perimeter screening for operator protection and high‑temperature equipment safety.
Technical Principles
Weave Construction (Ferrule Type):
Warp and weft wire ropes interlace in a plain over‑under pattern. Each intersection is permanently locked by a pressed stainless steel ferrule, creating precise, uniform diamond openings with high rigidity, smooth edges, and consistent panel geometry for architectural and safety applications.
Wire Rope Construction:
7×7 (1.2–2.4mm) uses 49 wires for stiff, abrasion‑resistant panels. 7×19 (3.2–4.0mm) uses 133 wires for greater flexibility and fatigue resistance, ideal for curved facades, zoo enclosures, and marine barriers. (198 characters).
Material Advantage:
SS316 contains molybdenum for superior corrosion resistance in saltwater and chlorides. PVDF coating adds UV resistance, color options, and extra protection, extending lifespan to 25+ years in harsh coastal or industrial environments. (200 characters).
1.D-shackle for connecting mesh edges to turnbuckles and edge cables
2.Single hole aluminum ferrule for crimping rope ends
3.Open body turnbuckle for fine tension adjustment
4.Wire rope clip for securing loop ends
5.Expansion bolt for anchoring into concrete structures
Required Tools: Stainless steel cable cutter, crimping tool, wrench set, hydraulic tensioner, tensiometer, level, tape measure, and drill.
