EE28 Power Transformer 220VAC 24VAC Ferrite Core High Frequency 12V 50.5W Copper Winding Multi-Winding Coil 50Hz/60Hz Transformer
Price:
T/T, Paypal
MOQ:
100PCS
Delivery Time:
2-4Weeks
Brand:
ZHY
Product Description
Features:
Inductance is measured at 100 kHz, 0.25 Vrms.
DCR is with the windings connected in parallel.
Leakage inductance is for both windings of the primary with the secondary windings shorted.
Turns ratios are with the primary and secondary windings connected in parallel.
3000 Vrms isolation from primary to secondary windings
