NEMA24 Brushless DC Motor with 60mm Square Flange 24V/48V 200W-400W High Torque BLDC Motor for Industrial Automation

Product Overview

The NEMA24 Brushless DC Motor with 60mm Square Flange is designed for industrial automation equipment requiring high efficiency, long service life, and stable speed control. Available in 24VDC and 48VDC with power ratings from 200W to 400W, this BLDC motor provides excellent torque output while consuming less energy than traditional AC induction motors.

Its compact 60mm square frame makes it suitable for installations where space is limited while delivering reliable continuous operation in demanding industrial environments.

Key Features

• 60mm (NEMA24) square frame
• Available voltage: 24VDC / 48VDC
• Output power: 200W–400W
• High efficiency up to 90%
• High starting torque
• Low vibration and low noise
• Long service life with maintenance-free design
• Precise electronic speed control
• CW/CCW reversible rotation
• Compatible with planetary gearbox and gear reducer
• Optional encoder and brake
• IP54/IP65 protection available
• CE & RoHS compliant

Product Advantages

High Efficiency Energy Saving

Compared with conventional AC motors, the brushless DC motor achieves significantly higher efficiency, reducing power consumption while maintaining stable torque output.

Maintenance-Free Operation

Without carbon brushes, there is no brush wear or regular replacement, reducing maintenance costs and downtime.

Excellent Speed Regulation

Combined with a dedicated BLDC driver, the motor offers accurate speed control over a wide operating range.

High Torque Density

Provides more output torque in a compact 60mm frame, making it ideal for equipment requiring high power within limited installation space.

Quiet Operation

Electronic commutation eliminates brush friction, resulting in lower operating noise and smoother performance.

Typical Applications

The NEMA24 Brushless DC Motor is widely used in:

• Industrial Automation Equipment
• Conveyor Systems
• Packaging Machinery
• Textile Machinery
• Food Processing Equipment
• AGV & AMR Robots
• Mobile Robots
• CNC Equipment
• Medical Devices
• Printing Machines
• Semiconductor Equipment
• Automatic Doors
• Lift Systems
• Material Handling Equipment
• Electric Actuators

FAQ

Q: What's your main products?
A:We currently produce Stepper motors, Brushless Dc Motors, Brushed Dc Motors, Spindle motor, Ac Motors and drivers etc. You can check the specifications for above motors on our website and you can email us to recommend needed motors per your specification too.

Q:How to select a suitable motor?
A:If you have motor pictures or drawings to show us, or you have detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed life time and noise level etc, please do not hesitate to let us know, then we can recommend suitable motor per your request accordingly.

Q:How do you make sure motor quality?
A:We have our own inspection procedures: for incoming materials, we have signed sample and drawing to make sure qualified incoming materials; for production process, we have tour inspection in the process and final inspection to make sure qualified products before shipping.

Q:What's your lead time?
A:Generally speaking, our regular standard product will need 15-25days, a bit longer for customized products. But we are very flexible on the lead time, it will depends on the specific orders

Q:What's the minimum order quantity?
A:Our minimum order quantity depends on different motor models, please email us to check. Also, we usually do not accept personal use motor orders.

Q:What's your shipping method for motors?
A:For samples and packages less than 100kg, we usually suggest express shipping; For heavy packages, we usually suggest air shipping or sea shipping. But it all depends on our customers' needs.
