200W • 400W • 600W High Torque AC/DC Servo Motors
High-performance 60mm servo motors with 200W, 400W and 600W output. AC220V & DC24/48V options, high torque, 3000RPM, compact design for CNC, AGV, robotics and automation equipment.
Our 60mm Servo Motors are designed for industrial motion control systems requiring high precision, fast response and reliable torque output. Available in 200W, 400W and 600W, these compact servo motors provide excellent positioning accuracy, smooth operation and high efficiency.
Supporting AC220V and DC24V/48V power options, they are ideal for CNC machines, packaging equipment, AGVs, semiconductor machinery, textile equipment, conveyors and automated production lines.
Whether replacing traditional AC induction motors or upgrading existing automation equipment, our 60mm servo motors deliver superior dynamic performance with lower energy consumption.
Key Features
High Torque Output
Optimized electromagnetic design delivers stable torque over the full speed range.
Compact 60mm Square Frame
The 60mm flange design saves installation space while providing excellent mechanical strength.
High-Speed Operation
Rated Speed:3000 RPM
Supports rapid acceleration and deceleration with accurate speed control.
Multiple Voltage Options
Available power supply: AC 220V or DC 24/48V
Suitable for both industrial and mobile automation systems.
High Precision Motion Control
Compatible with closed-loop servo systems featuring:
High positioning accuracy.
Low vibration
Fast response
Stable speed regulation
Smooth low-speed operation
| Motor Model | Out Power | Rated Voltage | Rated Current | Rated Torque | Max. Torque | Rated Speed | Adapted Driver |
| kW | V | A | N·m | N·m | RPM | ||
| 60SFH020 | 0.2 | AC220 / DC24/48 | 1.4 | 0.64 | 2.24 | 3000 | M864S / HR1 |
| 60SFH040 | 0.4 | AC220 / DC24/48 | 2.6 | 1.27 | 5.08 | 3000 | M864S / HR1 |
| 60SFH060 | 0.6 | AC220 / DC24/48 | 3.5 | 1.91 | 6.68 | 3000 | M864S / HR1 |
Applications
Our 60mm servo motors are widely used in:
- CNC Machines
- Pick & Place Systems
- Industrial Robots
- AGV & AMR
- Packaging Machines
- Conveyor Systems
- Semiconductor Equipment
- Textile Machinery
- Medical Devices
- Printing Equipment
- Food Processing Equipment
- Laser Cutting Machines
- Automatic Assembly Lines
Why Choose Our 60mm Servo Motors?
High Efficiency
Up to 90%+ energy efficiency compared with conventional motors.
Excellent Dynamic Response
Fast acceleration and deceleration improve machine productivity.
Low Noise Operation
Optimized rotor balancing reduces vibration and operating noise.
Long Service Life
High-quality bearings and precision manufacturing ensure reliable long-term operation.
OEM & ODM Available
Support for customized:
Shaft dimensions
Encoder type
Brake option
Cable length
Connector
Mounting dimensions
IP protection level
FAQ
Q: What's your main products?
A:We currently produce Stepper motors, Brushless Dc Motors, Brushed Dc Motors, Spindle motor, Ac Motors and drivers etc. You can check the specifications for above motors on our website and you can email us to recommend needed motors per your specification too.
Q:How to select a suitable motor?
A:If you have motor pictures or drawings to show us, or you have detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed life time and noise level etc, please do not hesitate to let us know, then we can recommend suitable motor per your request accordingly.
Q:How do you make sure motor quality?
A:We have our own inspection procedures: for incoming materials, we have signed sample and drawing to make sure qualified incoming materials; for production process, we have tour inspection in the process and final inspection to make sure qualified products before shipping.
Q:What's your lead time?
A:Generally speaking, our regular standard product will need 15-25days, a bit longer for customized products. But we are very flexible on the lead time, it will depends on the specific orders
Q:What's the minimum order quantity?
A:Our minimum order quantity depends on different motor models, please email us to check. Also, we usually do not accept personal use motor orders.
Q:What's your shipping method for motors?
A:For samples and packages less than 100kg, we usually suggest express shipping; For heavy packages, we usually suggest air shipping or sea shipping. But it all depends on our customers' needs.
