Loose Tube Fiber Optic Outdoor Cable Single Mode GYFXTY 2 FRP 6 Core 8.2mm Diameter
Price:
500-3000RNB/KM
MOQ:
20km
Delivery Time:
It depends on the actual situation
Brand:
MingTong
Product Description
2 FRP 6 Core Single Mode Fiber Optic Cable GYFXTY
Product Overview
| Brand | TW-SCIE OR OEM |
| Optical Fiber Type | Single Mode G652D |
| Jacket Material | PE |
| Fiber Count | 6 |
| Jacket Color | Black |
| Strength Member | 2 Parallel FRP |
| Cable Diameter | 8.2mm |
| Length | 2000m per roll or customized |
| Gross Weight | 35 kgs |
Construction Features
The GYFXTY central beam tube optical cable structure inserts 250μm optical fiber into a loose tube made of high modulus material, with the loose tube filled with waterproof compound. The loose tube is wrapped with a layer of aramid yarn (Made In China) longitudinally, and water blocking material is added between the aramid yarn and the loose tube to ensure optical cable compactness and longitudinal water blocking. Two parallel steel FRP are placed on both sides and the polyethylene sheath is extruded into a cable.
Technical Specifications
| Parameter | Details | Value |
|---|---|---|
| NO. of cable | 6 | |
| Fiber model | G.652D | |
| Strength Member | Material | FRP |
| Diameter (±0.05)mm | 1.8 | |
| Loose Tube | Material | PBT |
| Diameter (±0.06)mm | 1.8 | |
| Thickness (±0.03)mm | 0.35 | |
| Loose Tube | The max core No./tube | 12 |
| Outer Sheath | Material | PE |
| Cable Diameter (±0.2)mm | 6.7 | |
| Cable Weight (±5) kg/km | 38 | |
| Min. Bending Radius | Without tension | 10.0× Cable-φ |
| Under Maximum Tension | 20.0× Cable-φ | |
| Temperature range (°C) | Installation | -20 to +60 |
| Transport & Storage | -40 to +70 | |
| Operation | -40 to +70 |
