Corrugated Fin Edge Seam Transformer Tank Welding Machine Stationary 5kW

Price Negotiable

Price: $124,200-500,000 / set

MOQ: 1 set

Delivery Time: Negotiable

Brand: Tongli

Product Description

The ZHJ Corrugated Fin Edge Seam Welding Machine is a special equipment to weld the pre-formed corrugated fin edges of each fin and also the top reinforcing rod. The machine consists of mechanical system, transmission device, pne umatic system and electrical control system. The machine can simultaneously welds the fin edges of each fin on both sides of the corrugated panel according to the input parameters. The weld penetration is deep, high strength, and smooth-surfaced with no leakage risks.

Specifications:

Item	Parameters
Model	ZHJ- 1300	ZHJ- 1 600
B Corrugation fin width	300 ~ 1 300mm	300 ~ 1 600mm
S Corrugation fin thickness	1 . 0 ~ 1 . 5 mm
H Corrugation fin height	50 ~ 400mm
T Corrugation fin pitch	≥ 40mm
Power of electric control system	3 . oKW 3 phase AC380 , 50Hz
Welding power	2 x 14 . 7kw 3 phase AC380 , 50Hz
Welding torch cooling	circulating water cooling (10L/min)
Suitable medium	Argon (≥96% purity)
	compressed air (p ≥0 . 5Mpa)
Outline dimension (LXWXH)	2700mm x 1 600mm x 2200mm	2700mm x 1 900mm x 2200mm
Total weight	2300 kg	2750 kg
