Background Suppression Photoelectric Sensors 50mm-1200mm Detection Distance

Price Negotiable

Price: $30

MOQ: 1

Delivery Time: 5~8 work days

Brand: BOJKE

Product Description

Product Description

Model No	BG-1000N/BG-1000P
Detection Type	diffuse reflector
Detection Distance	50mm-1200mm
Light Spot Size	3mm~5mm
Hysteresis Range	10% between black background and white background
Detection Object	semi transparent or dark colored objects
Repeat Accuracy	horizontal detection <1mm Vertical detection <0.2mm
Sensitivity Adjustment	knob adjustment
Output Type	NPN open collector
Switching Mode	Light.on
Response Time	<1ms
Response Frequency	1KHz
Light Source	650nm visible red light
Working Voltage	DC 12~24V ±10%
Residue Voltage (Voltage drop)	<3V
Max Load Current	100mA
Consumption (no-load) Current	<25mA
Ambient Illumination	Incandescent lamp ≤ 3000Lux; Sunlight ≤ 10000Lux
Ambient Temperature	operation temperature:-25℃~75℃；storage:-40℃~85℃,no freezing
Ambient Humidity	operation humidity: 5%~85% RH；storage:5%~95% RH no condensation
Protection Circuit	polarity reversal protection/surge protection/short circuit protection
Protection Level	IP65
Indicator Light	Orange
Connection Type	3 core 2 meter standard cable
Housing Material	PC+ABS
Withstand Voltage	AC 500V, 50/60Hz, 1 minute
Vibration Resistance	10～55Hz, dual amplitude 1.5mm, X/Y/Z directions each 2 hours
Impact Resistance	500m/S2, X,Y,Z directions each 3 times
Insulation Impedance	Above 20M Ω (DC 500V megohmmeter)
