Commercial Managed 24 Port Gigabit PoE Switch, 4 x 1.25G SFP Uplink Ports, 1 Console Web Management, Rack Mount, IEEE802.3af/at for IP Camera, Wireless AP
Commercial Managed 24 Port Gigabit PoE Switch, 4 x 1.25G SFP Uplink Ports, 1 Console Web Management, Rack Mount, IEEE802.3af/at for IP Camera, Wireless AP
Product Description
Our commercial managed 24-port Gigabit PoE switch combines 24 gigabit PoE electrical ports with 4 SFP fiber uplink slots, supporting long-distance fiber networking to extend network coverage flexibly. Equipped with a Console port for local serial debugging, the switch provides user-friendly Web-based management. Network administrators can easily configure VLAN, QoS, port aggregation, storm control, IGMP snooping, port mirroring and other rich Layer 2 features via the web interface.
All PoE ports comply with IEEE 802.3af/at standards. The switch automatically detects compatible PD devices and delivers safe power supply. The aluminum alloy heat dissipation shell adopts fanless passive cooling design, effectively reducing operating temperature and improving long-term reliability. With included rack mounting brackets, it can be quickly installed into standard 19-inch equipment cabinets.
Built for commercial networking scenarios, this managed PoE switch is widely deployed in video surveillance systems, enterprise office networks, hotel Wi-Fi systems, smart parks and access control projects. It delivers full gigabit bandwidth, stable PoE power output and complete management capabilities to build a reliable wired network backbone.
Product Features
- 24 × 10/100/1000Mbps PoE RJ45 ports, compliant with IEEE 802.3af/at PoE standard
- 4 × 1.25G SFP uplink fiber slots for long-distance fiber transmission
- 1 × Console port for local serial management and troubleshooting
- Intuitive Web GUI management, full set of Layer 2 network functions
- Supports VLAN, QoS, Port Trunking, IGMP Snooping, Storm Control, Port Mirroring
- Auto PoE detection, identify PD devices automatically; per-port over-current & short-circuit protection
- Aluminum alloy heat dissipation housing, fanless passive cooling, zero noise
- 19-inch rack-mount design for standard cabinet installation
- Full gigabit non-blocking bandwidth, ideal for HD video stream and large data transmission
- Supports continuous 24/7 operation for commercial network environments
Product Specifications
| Item | Specification |
|---|---|
| Model | Managed 24G PoE + 4SFP |
| Ethernet Ports | 24 × 10/100/1000Mbps RJ45 PoE Ports |
| SFP Ports | 4 × 1.25G SFP Uplink Slots (SFP transceivers not included) |
| Console Port | 1 × RJ45 Console port for local management |
| PoE Standard | IEEE 802.3af / IEEE 802.3at |
| PoE Protection | Auto PD detection, over-current, short-circuit protection per port |
| Management | Web GUI management, Console CLI management |
| Layer 2 Features | VLAN, QoS, Port Aggregation, IGMP Snooping, Storm Control, Port Mirroring |
| Switching Capacity | 56Gbps |
| Forwarding Rate | 41.6Mpps |
| Installation | 19-inch rack mount |
| Housing | Aluminum alloy heat dissipation shell |
| Cooling Method | Fanless passive cooling |
| Operating Temperature | 0℃ ~ +50℃ |
| Storage Temperature | -20℃ ~ +70℃ |
| Humidity | 5% ~ 95% non-condensing |
| Power Input | DC power input (Total PoE power budget optional) |
| Dimension | 1U rack size |
Note: Total PoE power can be customized as requested. SFP modules are sold separately.
Application Scenarios
- IP camera video surveillance systems
- Enterprise & office local area networks
- Wireless AP coverage for hotels, campuses and smart parks
- Smart building and access control systems
- Retail store chain networks
- Residential community monitoring network
