Fast Passing Swing Turnstile Access Gate , IC Card Access Control Turnstile Gate For Campus Entrances
The JSD-B15(M) Fast Passing Swing Turnstile is designed for high-efficiency pedestrian access management in campuses, office buildings, residential communities, and public facilities. Featuring a slim “Small Waist” streamlined appearance, the gate combines modern aesthetics with reliable security performance. Powered by a DC brushless motor, it delivers fast opening speed, smooth operation, and long service life exceeding 3 million cycles. The turnstile supports one-way or two-way traffic control and can integrate with IC/ID card readers, QR scanners, face recognition devices, and fingerprint systems. Built with durable 304 brushed stainless steel and multiple infrared sensors, the gate provides anti-tailgating, anti-pinch, and safe passage management for both indoor and outdoor environments.
-
Elegant Slim Design
The streamlined chassis design offers a modern appearance suitable for campuses, office lobbies, commercial buildings, and smart facilities.
-
Fast and Smooth Passage
Equipped with a DC brushless motor, the gate opens within 0.5 seconds, improving pedestrian flow efficiency during peak hours.
-
Multiple Access Control Integration
Compatible with IC cards, ID cards, QR code scanners, face recognition terminals, and fingerprint devices for flexible access solutions.
-
Intelligent Safety Protection
Standard infrared sensors support anti-tailgating, anti-pinch, and obstacle detection to ensure safe pedestrian passage.
-
Durable Stainless Steel Structure
Manufactured from 304 brushed stainless steel with precision bending craftsmanship for corrosion resistance and long-term durability.
-
Easy Installation and Maintenance
Detachable terminals and modular internal structure simplify wiring, maintenance, and system upgrades.
-
Indoor & Outdoor Application
Stable performance under temperatures from -10°C to 60°C, suitable for various installation environments.
-
Long Service Life
Supports continuous operation with over 3 million opening and closing cycles, reducing maintenance costs.
| Item | Specification |
|---|---|
| Product Model | JSD-B15(M) |
| Drive Motor | DC Brushless Motor |
| Opening Speed | 0.5 Seconds |
| Passage Direction | One-way / Two-way |
| Power Input | AC220V±10%, 50Hz |
| Working Voltage | DC24V / DC12V |
| Communication Interface | RS485 / Optional TCP/IP |
| Input Signal | Dry Contact / 12V Pulse Signal |
| Infrared Sensors | Standard 4 Pairs |
| Barrier Material | Acrylic or Stainless Steel |
| Working Temperature | -10°C ~ 60°C |
| Humidity | 5% ~ 95% Non-condensing |
| Service Life | ＞3 Million Cycles |
| Application Environment | Indoor & Outdoor |
Controls unauthorized access during school hours while improving student passage efficiency and reducing congestion.
Provides secure employee access management and integrates with attendance and visitor systems.
Enhances residential security by preventing unauthorized pedestrian entry and tailgating.
Improves visitor flow management while maintaining a modern and professional entrance appearance.
Ensures controlled access and improves pedestrian security management in sensitive areas.
Supports rapid pedestrian verification and smooth traffic flow during peak periods.
Yes. The gate is designed for both indoor and outdoor environments and operates reliably under temperatures from -10°C to 60°C.
The turnstile supports IC cards, ID cards, QR code scanners, face recognition devices, and fingerprint systems.
Yes. The system can be configured for one-way or two-way pedestrian access.
The gate includes infrared anti-pinch detection, anti-tailgating functions, and obstacle protection for safe operation.
The chassis is made from high-quality 304 brushed stainless steel for durability and corrosion resistance.
The gate supports more than 3 million continuous opening and closing cycles.
Yes. RS485 is standard, and TCP/IP communication can be customized optionally.
The standard passage width is 1100 mm, and customization is available based on project requirements.
